Kaishan LGCY-30/8TK Portable Diesel Screw Compressor
Model: LGCY-30/8TK
The Kaishan LGCY-30/8TK is a portable diesel screw compressor delivering 30 m³/min at 8 bar, designed for heavy-duty industrial applications. Built with a robust diesel engine and advanced screw airend, it ensures reliable performance in remote construction, mining, and drilling sites. Its compact mobile design, low fuel consumption, and easy maintenance make it an ideal choice for projects requiring continuous compressed air supply. With a focus on durability and efficiency, this model meets the demands of B2B buyers seeking dependable equipment for challenging environments.
Technical Specifications
| Model | LGCY-30/8TK |
| Free Air Delivery | 30 m³/min (1060 CFM) |
| Working Pressure | 8 bar (116 psi) |
| Engine | Cummins / Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 3,200 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,200 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
8 bar (116 psi)
Free Air Delivery
30 m³/min (1060 CFM)
Weight
3,200 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,200 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
30 m³/min free air delivery at 8 bar working pressure
Fuel-efficient diesel engine (Cummins/Yuchai) with low emissions
Heavy-duty screw airend for reliable continuous operation
Intelligent control panel with automatic protection and diagnostics
Mobile design with towbar, brakes, and rugged chassis
High ambient temperature cooling system for harsh environments
Easy maintenance access and long service intervals
Compliance with international safety and quality standards
Applications
📍 Construction
Provides compressed air for pneumatic tools, concrete spraying, and foundation drilling.
Solution: The LGCY-30/8TK delivers consistent air power to operate multiple tools simultaneously, increasing on-site productivity.
📍 Mining
Powers rock drills, jackhammers, and other equipment in surface and underground mining.
Solution: Its robust design and high altitude capability ensure reliable performance in remote mining sites.
📍 Oil and Gas
Supports drilling operations and pipeline testing with high-pressure air.
Solution: The compressor's stable output and safety features meet the stringent requirements of oilfield applications.
📍 Rental Fleets
Ideal for rental companies serving diverse industries.
Solution: Easy transport, low maintenance, and durable construction reduce downtime and increase rental ROI.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-30/8TKThis model | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins/Yuchai)
- Screw airend
- Air filter
- Oil separator
- Cooling system (radiator and fan)
- Control panel
- Chassis with towbar and brakes
- Discharge valve and piping
Working Principle
The Kaishan LGCY-30/8TK operates on the principle of positive displacement using a twin-screw airend. A diesel engine drives the male and female rotors, which mesh to trap and compress air. As the rotors turn, the volume between them decreases, raising the air pressure. The compressed air then passes through a separator to remove oil and impurities before being discharged. The engine's power is transmitted via a coupling or belt, and the system includes valves, coolers, and filters to ensure efficient operation. The control system regulates engine speed and air intake to match demand, optimizing fuel consumption. This design provides smooth, pulsation-free air delivery with high efficiency and reliability, making it suitable for continuous heavy-duty use.
Detailed Features
- ▸High efficiency screw airend
- ▸Low fuel consumption
- ▸Automatic shutdown protection
- ▸Corrosion-resistant enclosure
- ▸Easy access for maintenance
- ▸Wide ambient temperature range
- ▸Compact and mobile design
- ▸Compliant with CE and ISO standards
Packaging & Shipping
The Kaishan LGCY-30/8TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a container, depending on size. Standard export packing includes shock-absorbing materials and moisture barriers. Delivery time is typically 30-45 days after order confirmation. Ports of shipment include Shanghai, Ningbo, or Qingdao, China. Custom packaging and labeling are available upon request.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2000 hours, whichever comes first. Our global service network provides 24-hour technical support and genuine spare parts. We offer on-site training for operators and maintenance personnel. Regular maintenance kits and troubleshooting guides are available to ensure optimal performance and extended equipment life.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-30/8TK?+
The LGCY-30/8TK delivers a free air delivery of 30 m³/min (1060 CFM) at a working pressure of 8 bar (116 psi). This output supports pneumatic tools, drilling rigs and sandblasting equipment on site.
What engine powers the LGCY-30/8TK?+
The LGCY-30/8TK uses a Cummins or Yuchai diesel engine. The diesel engine delivers strong torque and low fuel consumption for continuous operation where electricity is unavailable.
What air outlet ports does the LGCY-30/8TK have?+
The LGCY-30/8TK is fitted with G1.5×1 and G3/4×1 air outlet ports. These ports connect the compressor to pneumatic tools and drilling equipment.
What applications suit the LGCY-30/8TK?+
The LGCY-30/8TK suits construction, mining, oil and gas, and rental fleets. Its mobile design with towbar, brakes and rugged chassis supports use on remote construction, mining and drilling sites.
How mobile is the LGCY-30/8TK?+
The LGCY-30/8TK weighs 3,200 kg and measures 3,800 × 1,800 × 2,200 mm. It has a mobile design with towbar, brakes and rugged chassis for movement between job sites.
What maintenance features does the LGCY-30/8TK offer?+
The LGCY-30/8TK provides easy maintenance access and long service intervals. It also has an intelligent control panel with automatic protection and diagnostics.
What is the warranty on the LGCY-30/8TK?+
The LGCY-30/8TK carries a warranty of 12 months or 2000 hours, whichever comes first. A global service network provides 24-hour technical support and genuine spare parts.
How is the LGCY-30/8TK packaged and shipped?+
The LGCY-30/8TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a container. Delivery time is typically 30-45 days after order confirmation, with ports of shipment including Shanghai, Ningbo or Qingdao, China.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 30 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 8 bar / 30 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 8 bar / 30 m³/min · 115–254 mm
