Kaishan K6 DTH Drill Bit for Mining & Water Well

Name: Kaishan K6 DTH Drill Bit for Mining & Water Well
Brand: Kaishan
SKU: K6
Availability: InStock

Model: K6

The Kaishan K6 DTH drill bit is a high-performance down-the-hole button bit engineered for mining, quarrying, and water well drilling. Designed with premium tungsten carbide buttons and a rugged alloy steel body, the K6 delivers exceptional penetration rates and long service life in hard rock formations. Its optimized air channels ensure efficient cuttings removal, while the precision-machined splines guarantee a secure fit with standard DTH hammers. Whether you are drilling blast holes in granite or water wells in limestone, the Kaishan K6 provides reliable, cost-effective performance. Available in a range of diameters and thread types to match your specific drilling rig and hammer configuration. Backed by Kaishan's global service network and strict quality control, this bit is the ideal choice for contractors seeking durability and productivity in demanding drilling conditions.

Best For

Open-Pit Mining Quarrying & Aggregate Water Well Drilling Construction & Foundation

Technical Specifications

Model	K6
Type	DTH Button Bit
Size	76mm - 152mm (3" - 6")
Application	Mining, Quarrying, Water Well Drilling, Construction
Material	Alloy Steel Body with Tungsten Carbide Buttons
Weight	3.5kg - 25kg (depending on size)
Packing	Wooden Case / Pallet

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan K6 DTH drill bit is a premium down-the-hole button bit designed for professionals in mining, quarrying, construction, and water well drilling. As a core component of the Kaishan drilling tools lineup, the K6 combines advanced metallurgy with precision manufacturing to deliver outstanding performance in hard and abrasive rock formations. This bit is compatible with most standard DTH hammers, making it a versatile choice for contractors worldwide. ## Technical Features The K6 features a high-strength alloy steel body that undergoes rigorous heat treatment for maximum wear resistance and toughness. Tungsten carbide buttons are strategically positioned to optimize fracture efficiency and reduce regrinding. The bit's face design ensures even wear and consistent penetration rates. Large air holes and deep flutes facilitate rapid cuttings evacuation, preventing clogging and reducing energy loss. The splines are precision-machined to ensure a tight, wobble-free connection with the hammer, extending the life of both the bit and the hammer. Available in various diameters and thread configurations, the K6 can be tailored to your specific drilling conditions. ## Applications The Kaishan K6 is ideal for a wide range of drilling applications. In open-pit mining, it is used for blast hole drilling in hard rock such as granite, basalt, and taconite. In quarrying, it delivers reliable performance for aggregate production. For water well drilling, the K6 provides efficient penetration in limestone, sandstone, and other sedimentary formations. It is also suitable for construction projects requiring rock anchors, foundation drilling, and site investigation. The bit's robust construction ensures dependable operation even in the most challenging environments. ## Why Choose Kaishan K6 Kaishan is a globally recognized manufacturer of drilling equipment and tools, with decades of experience and a commitment to quality. The K6 DTH bit is produced in ISO-certified facilities using state-of-the-art CNC machining and heat treatment processes. Each bit undergoes strict inspection to ensure dimensional accuracy and material integrity. With a global distribution network and responsive after-sales support, Kaishan ensures that your drilling operations run smoothly. Choose the Kaishan K6 for superior productivity, extended service life, and lower cost per meter drilled.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

3.5kg - 25kg (depending on size)

Model

Type

DTH Button Bit

Size

76mm - 152mm (3" - 6")

Application

Mining, Quarrying, Water Well Drilling, Construction

Material

Alloy Steel Body with Tungsten Carbide Buttons

Packing

Wooden Case / Pallet

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Premium tungsten carbide buttons for high wear resistance and long life

✓

High-strength alloy steel body with advanced heat treatment

✓

Optimized face design for efficient rock fracture and even wear

✓

Large air holes and deep flutes for rapid cuttings removal

✓

Precision-machined splines for secure hammer connection

✓

Available in multiple diameters and thread types

✓

Compatible with most standard DTH hammers

✓

Strict quality control and ISO-certified manufacturing

Applications

📍 Open-Pit Mining

Blast hole drilling in hard rock formations such as granite, basalt, and iron ore.

Solution: Kaishan K6 DTH bit with wear-resistant carbide buttons ensures fast penetration and reduced downtime.

📍 Quarrying & Aggregate

Drilling blast holes for aggregate production in limestone, dolomite, and other quarry materials.

Solution: Optimized air channels and durable body deliver consistent performance and lower cost per ton.

📍 Water Well Drilling

Drilling water wells in sedimentary and metamorphic rock formations.

Solution: K6 bit provides efficient cuttings removal and reliable penetration in varied ground conditions.

📍 Construction & Foundation

Rock anchors, foundation piling, and site investigation drilling.

Solution: Precision splines and robust design ensure accurate hole alignment and long service life.

High Pressure Series Models

Compare specifications across the series to find the right model.

Model	Model	Type	Size	Application	Material	Inquire
K6This model	K6	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, Quarrying, Water Well Drilling, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote
K10	K10	DTH Drill Bit (Down-the-Hole Button Bit)	90–130 mm diameter (customizable)	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
K3	K3	DTH Drill Bit	76mm - 152mm	Mining, Quarrying, Water Well Drilling	Alloy Steel with Carbide Buttons	Get a Quote
K4	K4	DTH Drill Bit	Φ110 mm (standard); other sizes available	Mining, water well drilling, quarrying, construction	Alloy steel body with carbide button inserts	Get a Quote
K5	K5	DTH Button Bit	130 mm - 152 mm diameter	Mining, quarrying, water well drilling, foundation engineering	Alloy steel body with tungsten carbide buttons	Get a Quote
K8	K8	DTH Drill Bit	4 inch (102 mm) diameter	Mining, quarrying, water well drilling	Alloy steel body with tungsten carbide buttons	Get a Quote
K10	K10	DTH Hammer	10 inch	Mining, Water Well, Quarry, Construction	Alloy Steel	Get a Quote
K3	K3	DTH Hammer	3 inch	Mining, quarrying, water well drilling, construction	Alloy steel	Get a Quote
K30C	K30C	Down-the-Hole (DTH) Hammer	3 inch (76.2 mm) nominal	Mining, quarrying, water well drilling, construction	High-quality alloy steel, heat-treated	Get a Quote
K4	K4	DTH Hammer	4 inch	Mining, water well, quarry, construction	Alloy steel, heat-treated	Get a Quote
K40	K40	DTH Hammer	4 inch	Mining, quarrying, water well drilling, construction	High-strength alloy steel	Get a Quote
K40C	K40C	Down-The-Hole (DTH) Hammer	4-inch class (105-130mm hole diameter)	Mining, water well, quarry, construction drilling	Alloy steel, heat-treated	Get a Quote
K46	K46	DTH Hammer	4 inch	Mining, Quarrying, Water Well Drilling, Construction	High-Strength Alloy Steel	Get a Quote
K5	K5	Down The Hole (DTH) Hammer	5 inch	Mining, quarrying, water well, construction	Alloy steel, heat-treated	Get a Quote
K50	K50	Down-the-Hole (DTH) Hammer	5-inch class	Mining, quarrying, water well drilling, construction	Alloy steel, heat-treated	Get a Quote
K6	K6	DTH Hammer	6 inch	Mining, Water Well, Quarrying	Alloy Steel	Get a Quote
K8	K8	DTH Hammer	8 inch	Water well drilling, mining, quarrying	Alloy steel	Get a Quote
K80	K80	Down-the-Hole (DTH) Hammer	8 inch (203 mm)	Mining, Quarrying, Water Well Drilling	Alloy Steel	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Alloy steel body
Tungsten carbide buttons
Splines (shank)
Air holes
Flutes
Face design (concave/convex)
Retaining ring
Wear pads

Working Principle

The Kaishan K6 DTH drill bit operates on the principle of down-the-hole percussion. High-pressure air is delivered through the drill string to the DTH hammer, which houses a piston. The piston strikes the bit's shank repeatedly, transferring impact energy to the tungsten carbide buttons on the bit face. Simultaneously, the bit is rotated slowly by the drill rig. The combination of impact and rotation causes the carbide buttons to fracture the rock through a combination of crushing and chipping. Compressed air then flows through the bit's air holes and flutes, flushing the rock cuttings out of the hole and cooling the bit. The K6's design optimizes this process by ensuring efficient energy transfer, even button wear, and rapid cuttings evacuation, resulting in high penetration rates and extended bit life.

Detailed Features

▸High penetration rate in hard rock
▸Long service life and reduced regrinding
▸Even wear for consistent hole diameter
▸Efficient cuttings removal
▸Secure hammer connection
▸Available in various sizes and threads
▸Compatible with major DTH hammer brands
▸Cost-effective per meter drilled

Packaging & Shipping

Each Kaishan K6 DTH drill bit is carefully packed in a wooden case or pallet, with rust-proof coating and protective caps on threads and buttons. Standard export packaging ensures safe transport. For bulk orders, bits are palletized and shrink-wrapped. Container loading: 20ft container can hold approximately 500-800 bits depending on size; 40ft container can hold 1000-1500 bits. Lead time: 15-30 days after order confirmation. Port of shipment: Shanghai, Ningbo, or as per customer request. Air freight and express delivery are also available for urgent orders.

After-Sales Service

Kaishan offers comprehensive after-sales service for the K6 DTH drill bit. All products come with a 6-month warranty against manufacturing defects. Our global service team provides 24-hour technical support and troubleshooting. We offer on-site training for drilling operators to maximize bit performance and lifespan. A full range of spare parts and accessories is available for quick delivery. Our engineers can assist with bit selection, drilling parameter optimization, and failure analysis. With service centers in major mining regions, we ensure minimal downtime and maximum productivity for our customers.

Frequently Asked Questions

What is the Kaishan K6 DTH drill bit used for?+

The Kaishan K6 is a down-the-hole button bit used for drilling blast holes in mining, quarrying, water wells, and construction projects. It is designed for hard rock formations.

What sizes are available for the K6 bit?+

The K6 is available in various diameters, typically ranging from 76mm to 152mm, and with different thread types such as API 2 3/8", 3 1/2", and metric threads. Custom sizes can be ordered.

Which DTH hammers are compatible with the K6 bit?+

The K6 bit is compatible with most standard DTH hammers from major brands, including Kaishan, Atlas Copco, Sandvik, and others. Please specify your hammer model when ordering.

What is the expected service life of the K6 bit?+

Service life depends on rock conditions, drilling parameters, and operator skill. In typical hard rock, the K6 can drill 200-500 meters before regrinding is needed. Proper maintenance can extend life significantly.

Can I get custom branding on the bit?+

Yes, we offer OEM and ODM services. Custom logos, packaging, and specifications are available for bulk orders. Please contact our sales team for details.

What is the warranty and after-sales support?+

We provide a 6-month warranty against manufacturing defects. Our 24-hour technical support team is available to assist with any issues. We also offer training and spare parts supply.
