Kaishan K5 DTH Drill Bit for Mining & Water Well

Name: Kaishan K5 DTH Drill Bit for Mining & Water Well
Brand: Kaishan
SKU: K5
Availability: InStock

Model: K5

The Kaishan K5 DTH drill bit is a high-performance down-the-hole button bit engineered for demanding mining, quarrying, and water well drilling. Designed for 5-inch class DTH hammers, it delivers fast penetration, long service life, and reliable performance in hard rock formations. Manufactured from premium alloy steel with tungsten carbide buttons, the K5 features a robust shank and optimized flushing holes for efficient cuttings removal. Its balanced design reduces vibration and improves hole straightness, making it an ideal choice for blast hole drilling, water well construction, and foundation work. Compatible with standard DTH hammers and drill pipes, the K5 is a cost-effective solution for contractors seeking productivity and durability. Available in various face designs and button configurations to suit different rock conditions.

Best For

Open-Pit Mining Quarrying Water Well Drilling Foundation Engineering

Technical Specifications

Model	K5
Type	DTH Button Bit
Size	130 mm - 152 mm diameter
Application	Mining, quarrying, water well drilling, foundation engineering
Material	Alloy steel body with tungsten carbide buttons
Weight	Approx. 15-25 kg depending on size
Packing	Wooden case or carton, palletized for bulk

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan K5 DTH drill bit is a 5-inch class down-the-hole button bit designed for high-efficiency rock drilling in mining, quarrying, water well, and construction applications. As a core component of the DTH drilling system, it is engineered to withstand extreme impact and abrasion while delivering consistent penetration rates. The K5 is compatible with standard 5-inch DTH hammers and is available in flat face, convex face, and concave face designs to match various rock formations. ## Technical Features Manufactured from high-quality alloy steel, the K5 undergoes advanced heat treatment to achieve an optimal balance of hardness and toughness. Tungsten carbide buttons are precision-pressed and brazed into the bit body, ensuring excellent wear resistance and impact strength. The bit features optimized flushing holes that direct air to the cutting face, effectively removing cuttings and cooling the buttons. Its splined shank provides a secure connection to the hammer, while the robust body design minimizes breakage in tough drilling conditions. The K5 is available in diameters ranging from 130 mm to 152 mm, with various button shapes (spherical, ballistic, conical) to suit different rock hardness. ## Applications The Kaishan K5 DTH drill bit is widely used in open-pit mining, quarrying, water well drilling, geothermal exploration, and foundation engineering. It performs exceptionally well in hard and abrasive rock such as granite, basalt, and quartzite. Whether drilling blast holes, water wells, or anchor holes, the K5 delivers reliable performance and extended service life, reducing downtime and overall drilling costs. ## Why Choose Kaishan K5 With decades of expertise in drilling equipment, Kaishan ensures each K5 bit meets strict quality standards. The combination of premium materials, precise manufacturing, and rigorous testing results in a drill bit that maximizes productivity and minimizes cost per meter. Backed by global service and support, the K5 is the trusted choice for drilling professionals worldwide.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

Approx. 15-25 kg depending on size

Model

Type

DTH Button Bit

Size

130 mm - 152 mm diameter

Application

Mining, quarrying, water well drilling, foundation engineering

Material

Alloy steel body with tungsten carbide buttons

Packing

Wooden case or carton, palletized for bulk

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

5-inch class DTH button bit for mining, quarrying, and water well drilling

✓

Premium alloy steel body with advanced heat treatment for durability

✓

High-grade tungsten carbide buttons for excellent wear resistance

✓

Optimized flushing holes for efficient cuttings removal and cooling

✓

Splined shank ensures secure and stable connection to DTH hammer

✓

Available in various face designs and button configurations

✓

Reduces vibration and improves hole straightness

✓

Cost-effective solution with long service life and low cost per meter

Applications

📍 Open-Pit Mining

Blast hole drilling in hard rock such as granite, basalt, and iron ore.

Solution: Kaishan K5 DTH bit with spherical buttons provides fast penetration and long life, reducing drilling costs.

📍 Quarrying

Drilling blast holes for aggregate production in limestone and dolomite quarries.

Solution: The K5's robust design and optimized flushing ensure reliable performance in abrasive conditions.

📍 Water Well Drilling

Constructing water wells in hard rock formations for residential, agricultural, and industrial use.

Solution: K5 bit with ballistic buttons delivers efficient drilling and good hole straightness for well casing installation.

📍 Foundation Engineering

Drilling anchor holes and micropiles for foundation support in construction projects.

Solution: The K5's precise diameter and stable connection ensure accurate hole placement and efficient progress.

High Pressure Series Models

Compare specifications across the series to find the right model.

Model	Model	Type	Size	Application	Material	Inquire
K5This model	K5	DTH Button Bit	130 mm - 152 mm diameter	Mining, quarrying, water well drilling, foundation engineering	Alloy steel body with tungsten carbide buttons	Get a Quote
K10	K10	DTH Drill Bit (Down-the-Hole Button Bit)	90–130 mm diameter (customizable)	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
K3	K3	DTH Drill Bit	76mm - 152mm	Mining, Quarrying, Water Well Drilling	Alloy Steel with Carbide Buttons	Get a Quote
K4	K4	DTH Drill Bit	Φ110 mm (standard); other sizes available	Mining, water well drilling, quarrying, construction	Alloy steel body with carbide button inserts	Get a Quote
K6	K6	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, Quarrying, Water Well Drilling, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote
K8	K8	DTH Drill Bit	4 inch (102 mm) diameter	Mining, quarrying, water well drilling	Alloy steel body with tungsten carbide buttons	Get a Quote
K10	K10	DTH Hammer	10 inch	Mining, Water Well, Quarry, Construction	Alloy Steel	Get a Quote
K3	K3	DTH Hammer	3 inch	Mining, quarrying, water well drilling, construction	Alloy steel	Get a Quote
K30C	K30C	Down-the-Hole (DTH) Hammer	3 inch (76.2 mm) nominal	Mining, quarrying, water well drilling, construction	High-quality alloy steel, heat-treated	Get a Quote
K4	K4	DTH Hammer	4 inch	Mining, water well, quarry, construction	Alloy steel, heat-treated	Get a Quote
K40	K40	DTH Hammer	4 inch	Mining, quarrying, water well drilling, construction	High-strength alloy steel	Get a Quote
K40C	K40C	Down-The-Hole (DTH) Hammer	4-inch class (105-130mm hole diameter)	Mining, water well, quarry, construction drilling	Alloy steel, heat-treated	Get a Quote
K46	K46	DTH Hammer	4 inch	Mining, Quarrying, Water Well Drilling, Construction	High-Strength Alloy Steel	Get a Quote
K5	K5	Down The Hole (DTH) Hammer	5 inch	Mining, quarrying, water well, construction	Alloy steel, heat-treated	Get a Quote
K50	K50	Down-the-Hole (DTH) Hammer	5-inch class	Mining, quarrying, water well drilling, construction	Alloy steel, heat-treated	Get a Quote
K6	K6	DTH Hammer	6 inch	Mining, Water Well, Quarrying	Alloy Steel	Get a Quote
K8	K8	DTH Hammer	8 inch	Water well drilling, mining, quarrying	Alloy steel	Get a Quote
K80	K80	Down-the-Hole (DTH) Hammer	8 inch (203 mm)	Mining, Quarrying, Water Well Drilling	Alloy Steel	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Bit body (alloy steel)
Tungsten carbide buttons
Splined shank
Flushing holes
Face design (flat/convex/concave)
Button arrangement
Retaining ring
Wear-resistant coating

Working Principle

The Kaishan K5 DTH drill bit operates as part of a down-the-hole drilling system. Compressed air is supplied through the drill pipe to the DTH hammer, which contains a piston that strikes the bit's shank at high frequency. The impact energy is transmitted through the bit body to the tungsten carbide buttons, which crush and fracture the rock. Simultaneously, the bit is rotated slowly, allowing the buttons to chip away the rock in a circular pattern. The exhaust air from the hammer travels through the flushing holes in the bit, cooling the buttons and lifting cuttings to the surface. This combination of impact and rotation enables efficient drilling in hard rock formations. The K5's design ensures optimal energy transfer, effective flushing, and minimal wear, resulting in high penetration rates and long service life.

Detailed Features

▸High penetration rate in hard rock
▸Long service life and low cost per meter
▸Premium alloy steel body with heat treatment
▸High-grade tungsten carbide buttons
▸Optimized flushing for efficient cuttings removal
▸Secure splined shank connection
▸Available in multiple face designs and button shapes
▸Strict quality control and testing

Packaging & Shipping

Each Kaishan K5 DTH drill bit is packed in a sturdy wooden case or carton, with rust-proof protection and shock-absorbing material to ensure safe transport. Standard export packing is suitable for sea and air freight. For bulk orders, bits are palletized and wrapped in film. Container loading: 20ft container can hold approximately 500-800 pieces depending on size. Delivery time is 15-30 days after order confirmation. Ports of shipment: Shanghai, Ningbo, or as per customer request.

After-Sales Service

Kaishan offers comprehensive after-sales service for the K5 DTH drill bit. All products come with a 6-month warranty against manufacturing defects. Our global service team provides 24-hour technical support and troubleshooting. We offer on-site training for drilling operators and maintenance personnel. Genuine spare parts and buttons are available for prompt delivery. Customized solutions and technical consultation are available to optimize drilling performance. Contact our local dealer or Kaishan service center for assistance.

Frequently Asked Questions

What is the Kaishan K5 DTH drill bit used for?+

The K5 is a 5-inch class DTH button bit used for blast hole drilling in mining and quarrying, water well drilling, and foundation engineering. It is designed for hard rock formations.

What sizes are available for the K5 bit?+

The K5 is available in diameters from 130 mm to 152 mm. Custom sizes can be provided upon request.

What is the recommended DTH hammer for the K5 bit?+

The K5 is compatible with standard 5-inch DTH hammers, such as Kaishan's own series or other brands with matching shank.

How long does the K5 drill bit last?+

Service life depends on rock conditions and operating parameters. In medium-hard rock, it can drill hundreds of meters. Proper operation and maintenance extend life.

Can I customize the button shape and face design?+

Yes, we offer spherical, ballistic, and conical buttons, and flat, convex, or concave face designs to suit different rock conditions.

What is the warranty and delivery time?+

We provide a 6-month warranty. Delivery time is typically 15-30 days after order confirmation, depending on quantity.
