Kaishan LGCY-25/10TK Portable Diesel Screw Compressor
Model: LGCY-25/10TK
The Kaishan LGCY-25/10TK is a heavy-duty portable diesel screw compressor delivering 25 m³/min (883 CFM) at 10 bar, purpose-built for demanding industrial applications. Powered by a reliable diesel engine and engineered with Kaishan's proven twin-screw airend, this unit combines high free air delivery with fuel efficiency and rugged mobility. Its compact four-wheel chassis and robust canopy make it ideal for construction sites, mining operations, quarrying, and water well drilling where reliable compressed air is critical. The LGCY-25/10TK features advanced cooling, easy maintenance access, and comprehensive safety protections, ensuring continuous operation in harsh environments. With global service support and readily available spare parts, it offers a cost-effective solution for contractors and rental fleets seeking dependable portable air power.
Technical Specifications
| Model | LGCY-25/10TK |
| Free Air Delivery | 25 m³/min (883 CFM) |
| Working Pressure | 10 bar (145 psi) |
| Engine | Cummins or Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 2,800 kg |
| Dimension (L×W×H) | 3,200 × 1,600 × 2,200 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
10 bar (145 psi)
Free Air Delivery
25 m³/min (883 CFM)
Weight
2,800 kg
Dimension (L×W×H)
3,200 × 1,600 × 2,200 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 25 m³/min (883 CFM) at 10 bar working pressure
Fuel-efficient diesel engine compliant with emission regulations
Heavy-duty four-wheel chassis with towbar for superior mobility
Weather-resistant canopy and lockable doors for security and durability
Advanced control panel with automatic safety shutdowns
Large fuel tank for extended operation without refueling
Easy maintenance access with wide service doors
Proven Kaishan twin-screw airend for reliable performance
Applications
📍 Construction
Powering pneumatic breakers, jackhammers, and concrete pumps on building sites.
Solution: The LGCY-25/10TK delivers consistent high-volume air to run multiple tools simultaneously, increasing productivity.
📍 Mining & Quarrying
Operating rock drills, pneumatic loaders, and ventilation systems in harsh environments.
Solution: Its rugged chassis and dust-resistant canopy ensure reliable operation in mines and quarries, with easy transport between pits.
📍 Water Well Drilling
Providing air for down-the-hole hammers and drilling rigs.
Solution: High pressure and air flow support efficient drilling, while the diesel engine allows operation in remote locations without grid power.
📍 Sandblasting & Surface Preparation
Supplying air for sandblasting and painting equipment.
Solution: The compressor maintains steady pressure for consistent surface treatment, with a large tank for uninterrupted workflow.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-25/10TKThis model | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine
- Twin-screw airend
- Air-oil separator tank
- Cooling system (radiator and fan)
- Control panel
- Four-wheel chassis with towbar
- Weather-resistant canopy
- Intake air filter
Working Principle
The Kaishan LGCY-25/10TK operates on the principle of positive displacement using a twin-screw airend. A diesel engine drives the male and female rotors within the airend. As the rotors rotate, they trap air between their lobes and the casing, progressively reducing the volume and increasing the pressure. Oil is injected into the compression chamber to lubricate, seal, and cool the process. The compressed air-oil mixture then passes through a separator, where oil is removed and returned to the system, while clean compressed air is delivered to the outlet. The engine's speed is regulated to match air demand, optimizing fuel consumption. An advanced cooling system maintains optimal temperatures, and the control panel monitors parameters to ensure safe, efficient operation. This design provides continuous, pulse-free air delivery with high efficiency and reliability.
Detailed Features
- ▸High free air delivery: 25 m³/min (883 CFM) at 10 bar
- ▸Fuel-efficient diesel engine with low emissions
- ▸Heavy-duty four-wheel chassis for rough terrain
- ▸Weather-resistant and lockable canopy
- ▸Advanced control panel with automatic shutdowns
- ▸Large fuel tank for extended runtime
- ▸Easy maintenance access
- ▸Proven Kaishan twin-screw airend
Packaging & Shipping
The Kaishan LGCY-25/10TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard export packaging includes rust prevention and shock absorption. Delivery time is typically 30-45 days after order confirmation. Ports of shipment include Shanghai, Ningbo, or as per customer request. Dimensions and weight are optimized for efficient container loading.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2000 operating hours (whichever comes first) for the LGCY-25/10TK. A 24-hour global service hotline provides technical support and troubleshooting. We offer on-site training for operators and maintenance personnel. Genuine spare parts are available through our worldwide distribution network, ensuring minimal downtime. Preventive maintenance programs and extended warranty options are also available.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-25/10TK?+
The LGCY-25/10TK delivers a free air delivery of 25 m³/min (883 CFM) at a working pressure of 10 bar (145 psi). These figures suit high-volume compressed air demand on site.
What engine powers the LGCY-25/10TK portable diesel screw compressor?+
The LGCY-25/10TK is powered by a Cummins or Yuchai diesel engine. The diesel engine drives the Kaishan twin-screw airend.
What air outlet ports does the LGCY-25/10TK have for connecting equipment?+
The LGCY-25/10TK has air outlet ports of G1.5×1 and G3/4×1. These ports connect the compressor to pneumatic tools and drilling equipment.
What applications is the LGCY-25/10TK suitable for?+
The LGCY-25/10TK is used in construction, mining and quarrying, water well drilling, and sandblasting and surface preparation. Its 25 m³/min (883 CFM) at 10 bar supports DTH drilling and pneumatic tool operation.
How much does the LGCY-25/10TK weigh and what are its dimensions?+
The LGCY-25/10TK weighs 2,800 kg and measures 3,200 × 1,600 × 2,200 mm (L×W×H). The heavy-duty four-wheel chassis with towbar allows transport across rough terrain.
How is the LGCY-25/10TK packaged and shipped?+
The LGCY-25/10TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard export packaging includes rust prevention and shock absorption.
What warranty does Kaishan offer for the LGCY-25/10TK?+
Kaishan offers a warranty of 12 months or 2000 operating hours (whichever comes first) for the LGCY-25/10TK. A 24-hour global service hotline provides technical support and troubleshooting.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 25 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 10 bar / 25 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 10 bar / 25 m³/min · 115–254 mm
