Kaishan LGCY-17/18-18/15TK Portable Diesel Screw Compressor
Model: LGCY-17/18-18/15TK
The Kaishan LGCY-17/18-18/15TK portable diesel screw compressor delivers up to 17 m³/min of free air at 18 bar working pressure, making it a powerful and reliable solution for heavy-duty industrial applications. Built with a durable diesel engine and advanced screw air-end technology, this towable compressor is designed for continuous operation in demanding environments such as mining, quarrying, water well drilling, and construction. Its robust chassis, weather-resistant canopy, and efficient cooling system ensure stable performance even in extreme conditions. The LGCY-17/18-18/15TK combines high output, fuel efficiency, and low maintenance, offering excellent value for contractors and rental fleets. With easy service access and comprehensive safety features, it is an ideal choice for projects requiring dependable high-pressure air on the move.
Best For
Technical Specifications
| Model | LGCY-17/18-18/15TK |
| Free Air Delivery | 17 m³/min (600 CFM) |
| Working Pressure | 18 bar (261 psi) |
| Engine | Cummins / Yuchai diesel engine |
| Air Outlet Port | G1.5 × 1, G3/4 × 1 |
| Weight | 3,200 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
18 bar (261 psi)
Free Air Delivery
17 m³/min (600 CFM)
Weight
3,200 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 17 m³/min (600 CFM) at 18 bar working pressure
Fuel-efficient diesel engine (Cummins or Yuchai) with direct-coupled screw air end
Weather-resistant, sound-attenuated canopy for outdoor operation
Advanced cooling system for reliable performance in extreme temperatures
Intelligent control panel with automatic shutdown protection
Towable chassis with robust axles, brakes, and lights for easy transport
Large fuel tank for extended runtime and reduced refueling downtime
Easy service access with grouped maintenance points
Applications
📍 Water Well Drilling
High-pressure air is essential for driving down-the-hole hammers in water well drilling.
Solution: The LGCY-17/18-18/15TK provides consistent 18 bar pressure and 17 m³/min flow to power DTH hammers efficiently, ensuring fast penetration rates.
📍 Mining and Quarrying
Blast hole drilling requires reliable, high-volume air to operate drilling rigs in tough conditions.
Solution: With its rugged construction and high output, this compressor delivers dependable air for drilling blast holes, improving productivity in mines and quarries.
📍 Construction and Foundation Piling
Piling rigs and construction tools need a steady supply of compressed air on site.
Solution: The towable design and high flow rate make it easy to position near piling rigs, providing the necessary air power for efficient foundation work.
📍 Sandblasting and Surface Preparation
Sandblasting demands large volumes of clean, dry air at consistent pressure.
Solution: The LGCY-17/18-18/15TK delivers ample air to support multiple sandblasting nozzles, with optional aftercoolers and filters for clean air output.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-17/18-18/15TKThis model | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins or Yuchai)
- Screw air end
- Air filter and oil filter
- Oil separator tank
- Cooling system (radiator and fan)
- Control panel with gauges
- Towable chassis with axles and brakes
- Sound-attenuated canopy
Working Principle
The Kaishan LGCY-17/18-18/15TK operates on the principle of positive displacement rotary screw compression. A diesel engine drives the male and female rotors inside the screw air end. As the rotors mesh, air is trapped in the spaces between them and progressively compressed as the rotors turn. The compressed air then passes through a separator to remove oil, and is cooled by an aftercooler before being discharged. The engine's power is transmitted directly to the air end via a coupling, ensuring high efficiency and minimal energy loss. An advanced control system monitors key parameters such as discharge pressure, temperature, and engine speed, automatically adjusting the engine throttle to match air demand. This load-on-demand operation reduces fuel consumption and wear. The cooling system maintains optimal operating temperatures, even in harsh environments. Safety features include high-temperature and low-oil-pressure shutdowns, ensuring reliable and safe operation.
Detailed Features
- ▸High pressure 18 bar and flow 17 m³/min for demanding applications
- ▸Fuel-efficient diesel engine with direct drive
- ▸Weather-resistant and sound-attenuated enclosure
- ▸Advanced cooling for extreme temperatures
- ▸Intelligent control and safety shutdowns
- ▸Easy towing and positioning
- ▸Extended runtime with large fuel tank
- ▸Simple maintenance with grouped service points
Packaging & Shipping
The Kaishan LGCY-17/18-18/15TK is typically shipped in a 40-foot high-cube container (1 unit per container) or on a flat rack for RoRo shipment. Each unit is securely fastened with heavy-duty straps and protected with a wax coating and shrink wrap to prevent corrosion during transit. Delivery time is approximately 30-45 days after order confirmation, depending on destination. Ports of loading include Shanghai or Ningbo, China. For urgent orders, air freight or expedited sea freight can be arranged.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2,000 hours (whichever comes first) on the LGCY-17/18-18/15TK. Our global service network provides 24-hour technical support via phone or email. We offer on-site training for operators and maintenance personnel. Genuine spare parts are available from regional warehouses, ensuring quick delivery. Preventive maintenance kits and extended warranty options are also available.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-17/18-18/15TK?+
The LGCY-17/18-18/15TK delivers a free air delivery of 17 m³/min (600 CFM) at a working pressure of 18 bar (261 psi). This high-pressure, high-flow output supports demanding drilling and industrial applications.
What engine powers the LGCY-17/18-18/15TK?+
The LGCY-17/18-18/15TK uses a Cummins or Yuchai diesel engine. The engine is directly coupled to the screw air end for power transmission and fuel economy.
What air outlet ports does the LGCY-17/18-18/15TK have?+
The LGCY-17/18-18/15TK is fitted with one G1.5 air outlet port and one G3/4 air outlet port. These ports connect the compressor to the air supply line of the drilling equipment.
What applications is the LGCY-17/18-18/15TK suitable for?+
The LGCY-17/18-18/15TK is used for water well drilling, mining and quarrying, construction and foundation piling, and sandblasting and surface preparation. Its towable chassis and weather-resistant canopy support outdoor operation.
How much does the LGCY-17/18-18/15TK weigh and what are its dimensions?+
The LGCY-17/18-18/15TK weighs 3,200 kg and measures 3,800 × 1,800 × 2,500 mm (L×W×H). The towable chassis with axles, brakes and lights allows transport between sites.
How is the LGCY-17/18-18/15TK packaged for shipping?+
The LGCY-17/18-18/15TK is typically shipped in a 40-foot high-cube container, one unit per container, or on a flat rack for RoRo shipment. Each unit is fastened with heavy-duty straps and protected with a wax coating and shrink wrap.
What warranty does the LGCY-17/18-18/15TK come with?+
The LGCY-17/18-18/15TK carries a warranty of 12 months or 2,000 hours, whichever comes first. Global service support includes 24-hour technical support and on-site operator training.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 17 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 18 bar / 17 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 18 bar / 17 m³/min · 115–254 mm
