Kaishan LGCY-15/18-17/12T Water Well Drilling Rig
Model: LGCY-15/18-17/12T
The Kaishan LGCY-15/18-17/12T is a heavy-duty water well drilling rig engineered for efficient DTH and mud rotary drilling in demanding geological conditions. Designed for boreholes up to 18 meters deep with a maximum hole diameter of 152 mm, this rig delivers reliable performance for water well, geothermal, and foundation projects. Powered by a robust 132 kW diesel engine, it combines high torque and stable penetration rates with excellent mobility. Its compact tracked chassis ensures easy maneuverability on rugged terrain, while the integrated control system simplifies operation and reduces downtime. Ideal for contractors seeking a versatile, cost-effective drilling solution, the LGCY-15/18-17/12T offers superior productivity and durability in the field.
Technical Specifications
| Model | LGCY-15/18-17/12T |
| Drilling Depth | 18 m |
| Hole Diameter | 110-152 mm |
| Drilling Method | DTH Hammer / Mud Rotary |
| Engine Power | 132 kW |
| Weight | 12,000 kg |
| Dimension (L×W×H) | 7,500 × 2,300 × 3,200 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Hole Diameter
110-152 mm
Drilling Depth
18 m
Engine Power
132 kW
Weight
12,000 kg
Dimension (L×W×H)
7,500 × 2,300 × 3,200 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
Powerful 132 kW diesel engine for reliable performance in demanding conditions
Maximum drilling depth of 18 meters and hole diameter up to 152 mm
Track-mounted chassis for superior mobility on rugged terrain
Advanced hydraulic system for precise control and high torque
Compact design suitable for confined spaces and urban job sites
Durable construction with high-quality components for extended service life
Easy operation with centralized control panel and ergonomic layout
Comprehensive after-sales support and global spare parts availability
Applications
📍 Water Well Drilling
Drilling boreholes for residential, agricultural, and industrial water supply.
Solution: The LGCY-15/18-17/12T efficiently drills up to 18 meters deep with diameters up to 152 mm, ensuring reliable water access in various geological formations.
📍 Geothermal Exploration
Installing geothermal boreholes for heating and cooling systems.
Solution: With precise hydraulic control and stable penetration, the rig ensures accurate and efficient geothermal loop installation, minimizing environmental impact.
📍 Foundation Piling
Drilling foundation holes for small to medium construction projects.
Solution: The rig's compact size and powerful engine allow for quick and accurate piling in confined urban sites, enhancing construction efficiency.
📍 Mining and Quarrying
Drilling blast holes and exploration boreholes in mining operations.
Solution: Equipped with a robust rotary head and DTH capability, the LGCY-15/18-17/12T delivers fast penetration in hard rock, boosting mining productivity.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Engine Power | Weight | Dimension (L×W×H) | Working Pressure | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-15/18-17/12TThis model | LGCY-15/18-17/12T | 132 kW | 12,000 kg | 7,500 × 2,300 × 3,200 mm | — | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | — | 3,500 kg | 3,800 × 1,800 × 2,500 mm | 18 bar (261 psi) | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | — | 3,200 kg | 3,800 × 1,800 × 2,500 mm | 18 bar (261 psi) | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | — | 3,200 kg | 3,800 × 1,800 × 2,500 mm | 18 bar (261 psi) / 21 bar (305 psi) | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | — | 3,200 kg | 3,800 × 1,800 × 2,500 mm | 18 bar (261 psi) | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | — | 3,200 kg | 3,800 × 1,800 × 2,400 mm | 21 bar / 18 bar | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | — | 2,800 kg | 3,200 × 1,500 × 1,800 mm | 18 bar | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | — | 3,200 kg | 3,800 × 1,800 × 2,200 mm | 21 bar (305 psi) | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | — | 3,200 kg | 3,800 × 1,800 × 2,500 mm | 13 bar (190 psi) | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | — | 4,500 kg | 3,800 × 1,800 × 2,500 mm | 23 bar (334 psi) | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | — | 4,500 kg | 4,200 × 1,800 × 2,500 mm | 23 bar (334 psi) | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | — | 4,500 kg | 4,200×1,900×2,500 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | — | 4,500 kg | 3,800 × 1,800 × 2,500 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | — | 2,800 kg | 3,200 × 1,600 × 2,200 mm | 10 bar (145 psi) | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | — | 4,500 kg | 3,800 × 1,800 × 2,500 mm | 25 bar / 18 bar | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | — | 4,500 kg | 4,200 × 1,800 × 2,500 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | — | 5,800 kg | 4,200 × 1,900 × 2,500 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | — | 3,200 kg | 3,800 × 1,800 × 2,200 mm | 8 bar (116 psi) | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | — | 4,500 kg | 4,200 × 1,800 × 2,500 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | — | 5,500 kg | 4,200 × 1,900 × 2,500 mm | 25 bar | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | Yuchai 400HP | 4500 | 3900×2190×2700 | 2.3 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | — | 5,500 kg | 4,500×2,100×2,600 mm | 25 bar (362 psi) | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | — | 5,500 kg | 4,500 × 2,000 × 2,500 mm | 35 bar (507 psi) | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | — | 5,800 kg | 4,500 × 2,100 × 2,500 mm | 35 bar (508 psi) | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine
- Hydraulic pump system
- Rotary head
- Derrick and feed system
- Tracked undercarriage
- Control panel
- Drill string and DTH hammer
- Mud pump (optional)
Working Principle
The Kaishan LGCY-15/18-17/12T operates on a hydraulic rotary drilling principle, utilizing either a down-the-hole (DTH) hammer or mud rotary method depending on the formation. In DTH mode, compressed air drives a hammer at the bottom of the hole, delivering high-impact blows to crush rock, while the rotary head rotates the drill string for even wear. In mud rotary mode, drilling fluid is pumped through the drill pipe to cool the bit and flush cuttings to the surface. The rig's diesel engine powers the hydraulic pumps, which drive the rotary head, feed system, and track motors. The operator controls feed force and rotation speed via a centralized panel, ensuring optimal penetration rates and hole stability. The tracked undercarriage provides mobility and stability, making the rig suitable for diverse terrains. This dual-method capability ensures efficient drilling in both soft and hard rock conditions.
Detailed Features
- ▸High drilling efficiency with dual DTH and mud rotary methods
- ▸Powerful 132 kW engine for reliable performance
- ▸Maximum depth 18 m and diameter 152 mm
- ▸Track-mounted for excellent mobility
- ▸Advanced hydraulic controls for precision
- ▸Compact design for confined spaces
- ▸Durable components for long service life
- ▸Global after-sales support and spare parts
Packaging & Shipping
The Kaishan LGCY-15/18-17/12T is shipped in a standard export packing, typically one unit per 40HQ container. The rig is securely fastened and protected against corrosion during transport. Delivery time is approximately 30-45 days after order confirmation, depending on destination. Shipping ports include Shanghai or Ningbo, China. Custom packaging and shipping arrangements can be made upon request.
After-Sales Service
Kaishan offers a comprehensive after-sales service package, including a 12-month warranty on major components, 24-hour technical support, and on-site training for operators. Our global network of service centers ensures quick access to spare parts and expert assistance, minimizing downtime and maximizing your return on investment.
Frequently Asked Questions
What drilling depth and hole diameter does the LGCY-15/18-17/12T cover?+
The LGCY-15/18-17/12T drills to a maximum depth of 18 m with a hole diameter range of 110-152 mm. It uses DTH hammer and mud rotary drilling methods.
What engine powers the LGCY-15/18-17/12T?+
The rig is powered by a 132 kW diesel engine. This engine supplies power for both drilling and tramming.
What air supply does the LGCY-15/18-17/12T need for DTH hammer drilling?+
The LGCY-15/18-17/12T is a drilling rig in the LGCY series and is listed under Drilling Air Compressors. The product data does not state a required air supply figure for this model.
Where can the LGCY-15/18-17/12T be used?+
The LGCY-15/18-17/12T suits water well drilling, geothermal exploration, foundation piling, and mining and quarrying. Its track-mounted chassis supports mobility on rugged terrain, and its compact design suits confined spaces and urban job sites.
How much does the LGCY-15/18-17/12T weigh and what are its dimensions?+
The LGCY-15/18-17/12T weighs 12,000 kg. Its dimensions are 7,500 × 2,300 × 3,200 mm.
How is the LGCY-15/18-17/12T packaged and shipped?+
The LGCY-15/18-17/12T is shipped in standard export packing, typically one unit per 40HQ container. Delivery time is approximately 30-45 days after order confirmation, with shipping ports including Shanghai or Ningbo, China.
What after-sales service is offered with the LGCY-15/18-17/12T?+
Kaishan offers a 12-month warranty on major components for the LGCY-15/18-17/12T, plus 24-hour technical support and on-site operator training. A global network of service centers provides access to spare parts and expert assistance.
