Kaishan LGCY-33/35 Portable Diesel Screw Compressor
Model: LGCY-33/35
The Kaishan LGCY-33/35 portable diesel screw compressor delivers 33 m³/min of free air at 35 bar working pressure, making it one of the most powerful models in the Kaishan LGCY series for high-pressure drilling and industrial applications. Designed for demanding environments, it combines a heavy-duty diesel engine with an efficient twin-screw airend to ensure reliable performance in mining, water well drilling, and construction projects. The unit features a robust chassis, advanced cooling system, and intelligent control panel for easy operation and maintenance. With its high pressure and large air delivery, the LGCY-33/35 is ideal for DTH drilling, pipeline testing, and sandblasting where consistent air supply is critical. Kaishan's global service network ensures spare parts availability and technical support, maximizing uptime and productivity. This compressor is built to withstand harsh conditions while maintaining low fuel consumption and extended service intervals.
Best For
Technical Specifications
| Model | LGCY-33/35 |
| Free Air Delivery | 33 m³/min (1,165 CFM) |
| Working Pressure | 35 bar (507 psi) |
| Engine | Cummins or Yuchai diesel engine |
| Air Outlet Port | G2×1, G1×1 |
| Weight | 5,500 kg |
| Dimension (L×W×H) | 4,500 × 2,000 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
35 bar (507 psi)
Free Air Delivery
33 m³/min (1,165 CFM)
Weight
5,500 kg
Dimension (L×W×H)
4,500 × 2,000 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 33 m³/min (1,165 CFM) for large-scale operations
Working pressure of 35 bar (507 psi) suitable for deep drilling
Fuel-efficient diesel engine with low emissions
Advanced control panel with automatic protection and diagnostics
Heavy-duty chassis and suspension for rough terrain mobility
High-efficiency cooling system for extreme ambient temperatures
Applications
📍 Mining and Quarrying
High-pressure air for DTH drilling, blast hole drilling, and rock excavation.
Solution: The LGCY-33/35 provides consistent 35 bar air to power DTH hammers, increasing drilling speed and reducing fuel cost per meter.
📍 Water Well Drilling
Deep water well drilling requires reliable high-pressure air to lift cuttings and drive hammers.
Solution: With 33 m³/min capacity, it supports deep well drilling up to 300 meters, ensuring efficient penetration in hard rock formations.
📍 Oil and Gas Pipeline Testing
Pipeline purging, pressure testing, and drying demand oil-free and high-pressure air.
Solution: The compressor's efficient oil separation and steady pressure output make it ideal for pipeline commissioning and maintenance.
📍 Construction and Sandblasting
Sandblasting, concrete demolition, and foundation work require large volumes of compressed air.
Solution: The LGCY-33/35 can power multiple sandblasting pots simultaneously, improving surface preparation productivity on large projects.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-33/35This model | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi)★ | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins or Yuchai)
- Twin-screw airend
- Oil separation tank
- Cooling system (radiator and fan)
- Intake air filter
- Control panel with microprocessor
- Heavy-duty chassis with tires
- Discharge valves and piping
Working Principle
The Kaishan LGCY-33/35 operates on the principle of positive displacement using a twin-screw airend. A diesel engine drives the male and female rotors, which mesh to trap and compress air. As the rotors rotate, the volume between them decreases, raising the air pressure to the desired 35 bar. Lubricating oil is injected into the compression chamber to cool the air, seal clearances, and lubricate the rotors. The oil-air mixture then passes through a separation system where oil is removed and returned to the sump, while clean compressed air exits through the discharge valve. The engine speed is regulated by an electronic governor to match air demand, optimizing fuel consumption. A microprocessor controller monitors discharge pressure, temperature, and engine parameters, ensuring safe operation and automatic shutdown in case of faults. This design delivers high efficiency, low maintenance, and reliable performance in continuous duty cycles.
Detailed Features
- ▸High pressure 35 bar for deep drilling
- ▸Large air delivery 33 m³/min
- ▸Fuel-efficient engine with low emissions
- ▸Advanced control and monitoring system
- ▸Durable construction for harsh environments
- ▸Easy maintenance access
- ▸Extended service intervals
- ▸Global after-sales support
Packaging & Shipping
The Kaishan LGCY-33/35 is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container depending on configuration. Standard packaging includes shock-absorbing materials and weatherproof covering to prevent damage during transit. Delivery time is typically 30-45 days after order confirmation. Port of departure: Shanghai or Ningbo, China. For urgent orders, expedited shipping can be arranged.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2,000 hours (whichever comes first) on the LGCY-33/35. Our global service network provides 24-hour technical support and genuine spare parts delivery. We offer on-site installation and commissioning, as well as operator training to ensure safe and efficient use. Preventive maintenance kits and extended warranty options are available. With service centers in over 50 countries, we guarantee quick response and minimal downtime.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-33/35?+
The LGCY-33/35 delivers a free air delivery of 33 m³/min (1,165 CFM) at a working pressure of 35 bar (507 psi). This combination supports high-pressure, high-volume tasks such as deep-hole drilling.
What engine powers the LGCY-33/35 portable diesel screw compressor?+
The LGCY-33/35 is powered by a Cummins or Yuchai diesel engine. The fuel-efficient diesel engine is paired with a twin-screw airend for continuous operation.
What air outlet ports does the LGCY-33/35 have?+
The LGCY-33/35 has a G2×1 and G1×1 air outlet port. These ports connect the compressor to DTH drilling rigs and other high-pressure air equipment.
What applications is the LGCY-33/35 suitable for?+
The LGCY-33/35 is used in mining and quarrying, water well drilling, oil and gas pipeline testing, and construction and sandblasting. Its 35 bar working pressure and 33 m³/min free air delivery suit DTH drilling and pipeline testing.
How much does the LGCY-33/35 weigh and what are its dimensions?+
The LGCY-33/35 weighs 5,500 kg and measures 4,500 × 2,000 × 2,500 mm (L×W×H). The heavy-duty chassis and suspension support mobility on rough terrain.
How is the LGCY-33/35 packaged and shipped?+
The LGCY-33/35 is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container depending on configuration. Standard packaging includes shock-absorbing materials and weatherproof covering, with delivery typically 30-45 days after order confirmation from Shanghai or Ningbo, China.
What warranty and after-sales support come with the LGCY-33/35?+
The LGCY-33/35 carries a warranty of 12 months or 2,000 hours, whichever comes first. Kaishan's global service network provides 24-hour technical support, genuine spare parts delivery, on-site installation and commissioning, and operator training.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 33 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 35 bar / 33 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 35 bar / 33 m³/min · 115–254 mm
