Kaishan LGCY-45/25-37/35V Diesel Screw Compressor

Name: Kaishan LGCY-45/25-37/35V Diesel Screw Compressor
Brand: Kaishan
SKU: LGCY-45/25-37/35V
Availability: InStock

Model: LGCY-45/25-37/35V

The Kaishan LGCY-45/25-37/35V portable diesel screw compressor delivers up to 45 m³/min free air delivery at 25 bar working pressure, making it a powerful solution for heavy-duty drilling, mining, and construction applications. Powered by a reliable Cummins or Yuchai diesel engine, this two-stage screw compressor combines high pressure with high flow to drive DTH hammers and large-scale pneumatic tools efficiently. Its rugged mobile design ensures easy transport across demanding job sites, while advanced cooling and filtration systems guarantee stable performance in extreme environments. With low fuel consumption, extended service intervals, and comprehensive safety controls, the LGCY-45/25-37/35V reduces total cost of ownership and maximizes productivity. Ideal for water well drilling, quarry blasting, and pipeline testing, this compressor is engineered to meet the toughest industrial challenges. Kaishan's global service network provides dependable support, ensuring your operations run smoothly wherever you work.

Best For

Water Well Drilling Mining and Quarrying Construction Pipeline Testing

Technical Specifications

Model	LGCY-45/25-37/35V
Free Air Delivery	45 m³/min (1,590 CFM)
Working Pressure	25 bar (362 psi)
Engine	Cummins or Yuchai diesel engine
Air Outlet Port	G2×1, G1×1
Weight	5,500 kg
Dimension (L×W×H)	4,500×2,100×2,600 mm

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan LGCY-45/25-37/35V is a heavy-duty portable diesel screw compressor designed for high-pressure, high-flow applications. With a free air delivery of 45 m³/min (approximately 1,590 CFM) and a working pressure of 25 bar (362 psi), it stands out as a powerful solution for demanding industries such as mining, water well drilling, and construction. The model name reflects its capability: 45 for m³/min, 25 for bar, and 37/35V indicating engine and configuration variants. Built on Kaishan's proven two-stage screw technology, this compressor delivers reliable performance even in the most challenging environments. ## Technical Features The LGCY-45/25-37/35V integrates a robust Cummins or Yuchai diesel engine, known for fuel efficiency and durability. The two-stage air end is precision-engineered for high-pressure operation, ensuring minimal leakage and maximum efficiency. An advanced cooling system maintains optimal temperatures during continuous operation, while a heavy-duty air filter and oil separator protect internal components from dust and contaminants. The compressor is mounted on a rugged four-wheel chassis with a towbar, allowing easy movement across rough terrain. Safety features include automatic shutdown for high temperature and low oil pressure, plus emergency stop. The control panel offers intuitive monitoring of pressure, temperature, and fuel level. ## Applications This compressor excels in water well drilling, where it powers DTH hammers to penetrate hard rock formations. In mining and quarrying, it drives pneumatic drills and rock splitters for efficient blasting operations. For construction, it supports pile driving, concrete spraying, and sandblasting. Pipeline testing and cleaning also benefit from its high-pressure output. The LGCY-45/25-37/35V is equally suited for rental fleets due to its mobility and reliability. ## Benefits Operators appreciate the compressor's low fuel consumption, which reduces operating costs. Extended service intervals and easy access to maintenance points minimize downtime. The durable construction ensures a long service life, even in harsh conditions. Kaishan's global after-sales network provides prompt support and genuine spare parts, maximizing uptime. With its combination of power, efficiency, and reliability, the LGCY-45/25-37/35V is a smart investment for any heavy-duty operation.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Working Pressure

25 bar (362 psi)

Free Air Delivery

45 m³/min (1,590 CFM)

Weight

5,500 kg

Dimension (L×W×H)

4,500×2,100×2,600 mm

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

High free air delivery of 45 m³/min (1,590 CFM) for demanding applications

✓

Working pressure of 25 bar (362 psi) suitable for DTH drilling

✓

Fuel-efficient Cummins or Yuchai diesel engine

✓

Two-stage screw air end for high-pressure efficiency

✓

Rugged mobile chassis with four wheels and towbar

✓

Advanced cooling and filtration systems for extended service life

✓

Comprehensive safety controls with automatic shutdown

✓

Global after-sales support and genuine spare parts

Applications

📍 Water Well Drilling

High-pressure air is essential for driving DTH hammers in hard rock formations.

Solution: The LGCY-45/25-37/35V delivers 25 bar and 45 m³/min, ensuring fast penetration rates and efficient drilling.

📍 Mining and Quarrying

Pneumatic drills and rock splitters require reliable high-pressure air for blasting operations.

Solution: With its robust design and continuous duty capability, this compressor powers multiple tools simultaneously, boosting productivity.

📍 Construction

Pile driving, concrete spraying, and sandblasting demand consistent air flow.

Solution: The mobile chassis allows easy positioning on site, while the high flow rate supports various pneumatic tools without pressure drops.

📍 Pipeline Testing

Pipeline cleaning and pressure testing require oil-free or high-pressure air.

Solution: Equipped with efficient oil separation, the compressor provides clean air for testing, ensuring pipeline integrity and safety.

LGCY Series Models

Compare specifications across the series to find the right model.

Model	Model	Free Air Delivery	Working Pressure	Engine	Air Outlet Port	Inquire
LGCY-45/25-37/35VThis model	LGCY-45/25-37/35V	45 m³/min (1,590 CFM)★	25 bar (362 psi)	Cummins or Yuchai diesel engine	G2×1, G1×1	Get a Quote
LGCY-39/25	LGCY-39/25	39 m³/min (1,377 CFM)	25 bar (362 psi)	Cummins or Yuchai heavy-duty diesel	G1.5×1, G3/4×1	Get a Quote
LGCY-39/25A	LGCY-39/25A	39 m³/min	25 bar	Cummins / Yuchai diesel engine	G2×1, G1×1	Get a Quote
LGCY-33/25	LGCY-33/25	33 m³/min (1,165 CFM)	25 bar (362 psi)	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-33/25K	LGCY-33/25K	33 m³/min (1,165 CFM)	25 bar (362 psi)	Cummins or Yuchai diesel engine	G2×1, G3/4×1	Get a Quote
LGCY-27/25-29/18	LGCY-27/25-29/18	27 m³/min at 25 bar, 29 m³/min at 18 bar	25 bar / 18 bar	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-26/25	LGCY-26/25	26 m³/min (918 CFM)	25 bar (362 psi)	Cummins diesel engine	G2×1, G1×1	Get a Quote
LGCY-26/25K	LGCY-26/25K	26 m³/min (918 CFM)	25 bar (362 psi)	Cummins / Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-25/23-27/18K	LGCY-25/23-27/18K	25 m³/min (883 CFM)	23 bar (334 psi)	Cummins / Yuchai diesel engine, 18K series	G1.5×1, G3/4×1	Get a Quote
LGCY-23/23-25/18K	LGCY-23/23-25/18K	23 m³/min (812 CFM)	23 bar (334 psi)	Cummins / Yuchai diesel engine	G1.5 × 1, G3/4 × 1	Get a Quote
LGCY-21/21-23/18	LGCY-21/21-23/18	21 m³/min (740 CFM)	21 bar (305 psi)	Cummins / Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-19/21-21/18K	LGCY-19/21-21/18K	19 m³/min	21 bar / 18 bar	Cummins / Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-33/35	LGCY-33/35	33 m³/min (1,165 CFM)	35 bar (507 psi)	Cummins or Yuchai diesel engine	G2×1, G1×1	Get a Quote
LGCY-33/35A	LGCY-33/35A	33 m³/min (1,165 CFM)	35 bar (508 psi)	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-23/23-25/18	LGCY-23/23-25/18	23 m³/min	18 bar	Cummins / Yuchai	G1.5×1, G3/4×1	Get a Quote
LGCY-19/21-21/18	LGCY-19/21-21/18	21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar	18 bar (261 psi) / 21 bar (305 psi)	Cummins or Yuchai diesel engine, 6-cylinder, turbocharged	G1.5×1, G3/4×1	Get a Quote
LGCY-19/21-21/18X	LGCY-19/21-21/18X	21 m³/min (740 CFM)	18 bar (261 psi)	Cummins / Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-17/18-18/15T	LGCY-17/18-18/15T	17 m³/min (600 CFM)	18 bar (261 psi)	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-17/18-18/15TK	LGCY-17/18-18/15TK	17 m³/min (600 CFM)	18 bar (261 psi)	Cummins / Yuchai diesel engine	G1.5 × 1, G3/4 × 1	Get a Quote
LGCY-15/18-17/12T	LGCY-15/18-17/12T	—	—	—	—	Get a Quote
LGCY-21/13TK	LGCY-21/13TK	21 m³/min (740 CFM)	13 bar (190 psi)	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-25/10TK	LGCY-25/10TK	25 m³/min (883 CFM)	10 bar (145 psi)	Cummins or Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LGCY-30/8TK	LGCY-30/8TK	30 m³/min (1060 CFM)	8 bar (116 psi)	Cummins / Yuchai diesel engine	G1.5×1, G3/4×1	Get a Quote
LCGC-29/23 (crawler base)	LCGC-29/23 (crawler base)	29	2.3	—	G2×1, G³/₄×1	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Diesel engine (Cummins or Yuchai)
Two-stage screw air end
Air filter
Oil separator
Cooling system (radiator and fan)
Control panel
Four-wheel chassis with towbar
Safety shutdown system

Working Principle

The Kaishan LGCY-45/25-37/35V operates on a two-stage rotary screw principle. Air enters through a filter and is compressed in the first stage, then passes through an intercooler before entering the second stage for further compression to 25 bar. The screw rotors, driven by a diesel engine via a coupling, mesh to reduce volume and increase pressure. Oil is injected for lubrication, sealing, and cooling. The compressed air-oil mixture then enters a separator, where oil is removed and returned to the system. The clean, high-pressure air exits through the discharge valve. A sophisticated control system monitors parameters and adjusts engine speed to match air demand, optimizing fuel efficiency. Safety devices protect against overheating and low oil pressure, ensuring reliable operation.

Detailed Features

▸High pressure and flow for demanding drilling
▸Fuel-efficient diesel engine
▸Two-stage compression for efficiency
▸Rugged mobile design for easy transport
▸Advanced cooling for continuous operation
▸Easy maintenance access
▸Comprehensive safety controls
▸Global service network

Packaging & Shipping

The Kaishan LGCY-45/25-37/35V is shipped in a heavy-duty seaworthy package, with the compressor securely fastened to a steel frame and protected by a tarpaulin cover. It can be loaded into a 40-foot container or shipped as break-bulk, depending on quantity. Standard delivery time is 30-45 days after order confirmation. Ports of shipment include Shanghai or Ningbo, China. Custom packaging and shipping arrangements are available upon request.

After-Sales Service

Kaishan offers a comprehensive after-sales service package, including a 12-month warranty or 2,000 hours (whichever comes first) on major components. A 24-hour global support hotline provides technical assistance. We offer on-site training for operators and maintenance personnel. Genuine spare parts are available through our worldwide distribution network, ensuring quick delivery and reliable performance. Regular maintenance contracts can be tailored to your needs.

Frequently Asked Questions

What is the free air delivery and working pressure of the LGCY-45/25-37/35V?+

The LGCY-45/25-37/35V delivers 45 m³/min (1,590 CFM) free air delivery at 25 bar (362 psi) working pressure. This high-pressure, high-flow output suits demanding drilling and pneumatic tool applications.

What engine powers the LGCY-45/25-37/35V?+

The LGCY-45/25-37/35V is powered by a Cummins or Yuchai diesel engine. Both engine options are matched to the two-stage screw air end for high-pressure operation.

What equipment can the LGCY-45/25-37/35V drive?+

With 45 m³/min (1,590 CFM) at 25 bar (362 psi), the LGCY-45/25-37/35V drives DTH hammers and large-scale pneumatic tools. The air outlet ports are G2×1 and G1×1.

What applications suit the LGCY-45/25-37/35V?+

The LGCY-45/25-37/35V is used for water well drilling, mining and quarrying, construction, and pipeline testing. Its rugged mobile chassis with four wheels and towbar supports transport across demanding job sites.

How is the LGCY-45/25-37/35V packaged and shipped?+

The LGCY-45/25-37/35V ships in a heavy-duty seaworthy package, fastened to a steel frame with a tarpaulin cover. It can be loaded into a 40-foot container or shipped as break-bulk, with delivery in 30-45 days after order confirmation from Shanghai or Ningbo, China.

What warranty covers the LGCY-45/25-37/35V?+

The LGCY-45/25-37/35V carries a 12-month warranty or 2,000 hours, whichever comes first, on major components. A 24-hour global support hotline and genuine spare parts through the worldwide distribution network are available.

What are the dimensions and weight of the LGCY-45/25-37/35V?+

The LGCY-45/25-37/35V measures 4,500×2,100×2,600 mm (L×W×H) and weighs 5,500 kg. The rugged mobile chassis with four wheels and towbar allows transport across demanding job sites.
