Kaishan LGCY-21/13TK Diesel Screw Compressor
Model: LGCY-21/13TK
The Kaishan LGCY-21/13TK is a heavy-duty portable diesel screw compressor delivering 21 m³/min at 13 bar, purpose-built for high-demand drilling and industrial applications. Powered by a reliable Cummins or Yuchai diesel engine, it combines advanced screw airend technology with a robust mobile chassis for superior fuel efficiency and durability in the toughest environments. Its intelligent control system ensures precise pressure regulation and real-time monitoring, while the compact design allows easy transport and rapid deployment on construction sites, quarries, and oil fields. With a focus on reliability, low maintenance, and extended service intervals, the LGCY-21/13TK maximizes uptime and productivity. Whether you're operating DTH hammers, pneumatic tools, or sandblasting equipment, this compressor delivers consistent, oil-free air to keep your operations running smoothly. Backed by Kaishan's global service network and comprehensive warranty, it is the ideal choice for professionals seeking a powerful, efficient, and cost-effective compressed air solution.
Technical Specifications
| Model | LGCY-21/13TK |
| Free Air Delivery | 21 m³/min (740 CFM) |
| Working Pressure | 13 bar (190 psi) |
| Engine | Cummins or Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 3,200 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
13 bar (190 psi)
Free Air Delivery
21 m³/min (740 CFM)
Weight
3,200 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 21 m³/min (740 CFM) at 13 bar working pressure
Fuel-efficient Cummins or Yuchai diesel engine for reliable power
Advanced screw airend technology for oil-free air and low maintenance
Intelligent control system with real-time monitoring and fault diagnosis
Rugged mobile chassis with pneumatic tires for easy transport
Large fuel tank enabling extended operation without refueling
Weather-resistant enclosure with efficient cooling and noise reduction
Global service network and comprehensive warranty for peace of mind
Applications
📍 Mining & Quarrying
Powers DTH hammers and drilling rigs for blast hole drilling in open-pit mines and quarries.
Solution: The LGCY-21/13TK delivers high-pressure air to ensure fast penetration rates and efficient drilling, reducing downtime and increasing productivity.
📍 Construction
Operates pneumatic tools such as breakers, jackhammers, and sandblasting equipment on construction sites.
Solution: With its portable design and reliable air output, it provides consistent power for multiple tools, enhancing job site efficiency.
📍 Oil & Gas
Supports well drilling, pipeline testing, and pneumatic control systems in oil and gas fields.
Solution: The compressor's robust construction and high altitude capability ensure dependable performance in remote and harsh environments.
📍 Water Well Drilling
Provides compressed air for water well drilling rigs using DTH hammers.
Solution: Its high air delivery and pressure optimize drilling speed and hole cleaning, reducing overall project time and cost.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-21/13TKThis model | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins or Yuchai)
- Screw airend
- Air filter
- Oil separator
- Cooling system
- Control panel
- Fuel tank
- Discharge valve
Working Principle
The Kaishan LGCY-21/13TK operates on the principle of rotary screw compression. A diesel engine drives the male and female rotors inside the airend. As the rotors mesh, air is trapped in the spaces between them and progressively compressed as the volume decreases. Oil is injected into the compression chamber to lubricate, seal, and cool the process. The compressed air then passes through an oil separator, where the oil is removed, and a cooler reduces the air temperature. The intelligent control system regulates the engine speed and compressor load to match air demand, ensuring optimal efficiency. The air is delivered through a discharge valve at the required pressure. This continuous process provides a steady, pulse-free flow of compressed air, ideal for demanding applications.
Detailed Features
- ▸High efficiency screw airend for low energy consumption
- ▸Durable diesel engine with low fuel consumption
- ▸Intelligent control system with auto start/stop
- ▸Corrosion-resistant enclosure for harsh environments
- ▸Easy access for maintenance and service
- ▸Pneumatic tires and towbar for mobility
- ▸Large fuel tank for extended runtime
- ▸Safety features including overheat and overpressure protection
Packaging & Shipping
The Kaishan LGCY-21/13TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and desiccant to prevent moisture damage during transit. Delivery time is typically 30-45 days after order confirmation, depending on destination. We ship from major Chinese ports such as Shanghai or Ningbo, ensuring competitive freight rates and timely delivery worldwide.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2000 hours (whichever comes first) on the LGCY-21/13TK. Our global service network provides 24-hour technical support and genuine spare parts availability. We offer on-site training for operators and maintenance personnel to ensure optimal performance and safety. With service centers in over 100 countries, we guarantee quick response and minimal downtime for your operations.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-21/13TK?+
The LGCY-21/13TK delivers a free air delivery of 21 m³/min (740 CFM) at a working pressure of 13 bar (190 psi). It is a portable diesel screw compressor in the LGCY series. This output supports high-demand drilling and industrial applications.
What engine powers the LGCY-21/13TK?+
The LGCY-21/13TK is powered by a Cummins or Yuchai diesel engine. The diesel engine drives the screw airend for continuous duty in demanding environments. It is designed for fuel efficiency and long service life.
What equipment can the LGCY-21/13TK supply air to?+
With 21 m³/min (740 CFM) at 13 bar (190 psi), the LGCY-21/13TK can supply air to DTH hammers, pneumatic tools and sandblasting equipment. It is also suited to powering high-capacity drilling rigs. The air outlet ports are G1.5×1 and G3/4×1.
What applications is the LGCY-21/13TK suitable for?+
The LGCY-21/13TK is used in mining and quarrying, construction, oil and gas, and water well drilling. Its rugged mobile chassis with pneumatic tires supports transport and deployment on site. The weather-resistant enclosure supports operation in harsh environments.
How much does the LGCY-21/13TK weigh and what are its dimensions?+
The LGCY-21/13TK weighs 3,200 kg and measures 3,800 × 1,800 × 2,500 mm (L×W×H). The compact design allows transport and rapid deployment. It is fitted with pneumatic tires and a towbar for mobility.
What maintenance features does the LGCY-21/13TK have?+
The LGCY-21/13TK uses an advanced screw airend for oil-free air and low maintenance, with easy access for maintenance and service. The intelligent control system provides real-time monitoring and fault diagnosis. Safety features include overheat and overpressure protection.
How is the LGCY-21/13TK packaged and shipped?+
The LGCY-21/13TK is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and desiccant to prevent moisture damage during transit. Delivery time is typically 30-45 days after order confirmation, depending on destination.
What warranty does the LGCY-21/13TK come with?+
The LGCY-21/13TK carries a comprehensive warranty of 12 months or 2000 hours, whichever comes first. Kaishan's global service network provides 24-hour technical support and genuine spare parts availability. On-site training for operators and maintenance personnel is offered.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 21 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 13 bar / 21 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 13 bar / 21 m³/min · 115–254 mm
