Kaishan LGCY-23/23-25/18K Portable Diesel Screw Compressor
Model: LGCY-23/23-25/18K
The Kaishan LGCY-23/23-25/18K portable diesel screw compressor delivers 23 m³/min of free air at 23 bar working pressure, engineered for heavy-duty drilling and industrial applications. Powered by a reliable diesel engine and built on a rugged mobile chassis, this unit combines high-capacity air output with fuel-efficient screw technology. Its advanced air-end and cooling system ensure stable performance in demanding environments, from mining and quarrying to water well drilling and construction. With easy maintenance access, durable components, and Kaishan's global service support, the LGCY-23/23-25/18K is a dependable choice for professionals who require consistent high-pressure air on the move.
Best For
Technical Specifications
| Model | LGCY-23/23-25/18K |
| Free Air Delivery | 23 m³/min (812 CFM) |
| Working Pressure | 23 bar (334 psi) |
| Engine | Cummins / Yuchai diesel engine |
| Air Outlet Port | G1.5 × 1, G3/4 × 1 |
| Weight | 4,500 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
23 bar (334 psi)
Free Air Delivery
23 m³/min (812 CFM)
Weight
4,500 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
23 m³/min free air delivery and 23 bar working pressure for high-demand drilling
Fuel-efficient diesel engine (Cummins/Yuchai) with low emissions
Rugged mobile chassis with weather-resistant canopy for harsh environments
Advanced screw air end for reliable, continuous operation
Intelligent control system with automatic protection and fault diagnosis
Multiple air outlet ports (G1.5, G3/4) for versatile connectivity
Easy maintenance access with large service doors
Global service support and readily available spare parts
Applications
📍 Mining and Quarrying
High-pressure air for rock drills, jackhammers, and pneumatic tools in open-pit and underground mines.
Solution: The LGCY-23/23-25/18K provides consistent 23 bar air to power drilling equipment, increasing penetration rates and reducing downtime.
📍 Water Well Drilling
Reliable air for down-the-hole (DTH) hammers and rotary drilling in water well projects.
Solution: With 23 m³/min capacity, it supports deep drilling with efficient cuttings removal, ensuring fast and stable borehole completion.
📍 Construction and Infrastructure
Pneumatic power for foundation piling, tunnel support, and concrete spraying.
Solution: The portable design allows easy relocation on job sites, delivering high-pressure air for various construction tools.
📍 Oil and Gas Exploration
Air for seismic drilling and exploration activities in remote areas.
Solution: The rugged compressor withstands extreme conditions and provides reliable air for drilling shot holes, enhancing operational efficiency.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-23/23-25/18KThis model | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins/Yuchai)
- Screw air end
- Air-oil separator tank
- Cooling system (radiator and oil cooler)
- Intelligent control panel
- Air outlet valves (G1.5, G3/4)
- Heavy-duty mobile chassis with canopy
- Intake air filter and oil filter
Working Principle
The Kaishan LGCY-23/23-25/18K operates on the principle of rotary screw compression. A diesel engine drives the male and female rotors inside the air end. As the rotors mesh, air is trapped in the spaces between them and progressively compressed as the volume decreases. Oil is injected into the compression chamber to lubricate, seal, and cool the process. The compressed air-oil mixture then enters a separator, where oil is removed and recirculated, while clean air passes through a cooler and is delivered to the outlet. The system is regulated by an intelligent controller that adjusts engine speed and compressor load to match air demand, optimizing fuel efficiency. Safety features include high-temperature and low-oil shutdowns, ensuring reliable operation. This design delivers smooth, pulse-free air at high pressure, ideal for continuous duty in demanding environments.
Detailed Features
- ▸High-capacity 23 m³/min air delivery at 23 bar pressure
- ▸Fuel-efficient diesel engine with low operating costs
- ▸Durable screw air end for long service life
- ▸Weather-resistant canopy and robust chassis
- ▸Intelligent control with automatic protection
- ▸Multiple air outlets for flexible use
- ▸Easy maintenance with wide access doors
- ▸Worldwide service and spare parts network
Packaging & Shipping
The Kaishan LGCY-23/23-25/18K is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard export packaging includes shock-absorbing materials and moisture barriers. Delivery time is typically 30-45 days after order confirmation. Ports of shipment include Shanghai, Ningbo, or Qingdao, China. Custom packaging and labeling are available upon request.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2,000 hours (whichever comes first) for the LGCY-23/23-25/18K. Our global service network provides 24-hour technical support, on-site training for operators and maintenance staff, and quick access to genuine spare parts. We also offer preventive maintenance programs and extended warranty options to maximize uptime and reduce total cost of ownership.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-23/23-25/18K?+
The LGCY-23/23-25/18K delivers 23 m³/min (812 CFM) of free air at a working pressure of 23 bar (334 psi). These figures suit high-demand drilling and industrial applications.
What engine powers the LGCY-23/23-25/18K?+
The LGCY-23/23-25/18K is powered by a Cummins or Yuchai diesel engine. This diesel engine drives the screw air end for continuous field operation.
What air outlet ports does the LGCY-23/23-25/18K have?+
The LGCY-23/23-25/18K has one G1.5 air outlet port and one G3/4 air outlet port. These multiple outlets allow versatile connectivity to pneumatic equipment.
What applications is the LGCY-23/23-25/18K suitable for?+
The LGCY-23/23-25/18K is used in mining and quarrying, water well drilling, construction and infrastructure, and oil and gas exploration. Its 23 m³/min output at 23 bar supports DTH hammer and button bit drilling.
What are the dimensions and weight of the LGCY-23/23-25/18K?+
The LGCY-23/23-25/18K measures 3,800 × 1,800 × 2,500 mm (L×W×H) and weighs 4,500 kg. It is mounted on a rugged mobile chassis with a weather-resistant canopy.
How is the LGCY-23/23-25/18K packaged and shipped?+
The LGCY-23/23-25/18K is shipped with a protective wax coating and secured onto a flat rack or in a 40-foot container. Ports of shipment include Shanghai, Ningbo, or Qingdao, China.
What warranty does the LGCY-23/23-25/18K come with?+
The LGCY-23/23-25/18K carries a warranty of 12 months or 2,000 hours, whichever comes first. Global service support and genuine spare parts are available.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 23 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 23 bar / 23 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 23 bar / 23 m³/min · 115–254 mm
