Kaishan LGCY-27/25-29/18 Diesel Screw Compressor
Model: LGCY-27/25-29/18
The Kaishan LGCY-27/25-29/18 portable diesel screw compressor delivers dual pressure capability with 27 m³/min at 25 bar and 29 m³/min at 18 bar, making it ideal for high-demand drilling and industrial applications. Powered by a reliable Cummins or Yuchai diesel engine, this heavy-duty unit combines advanced screw airend technology with a robust mobile chassis for superior performance in remote locations. Its intelligent control system ensures precise pressure regulation, fuel efficiency, and safe operation, while the durable construction withstands the toughest job sites. Whether used for water well drilling, mining, or construction, the LGCY-27/25-29/18 provides consistent, oil-free air output to maximize productivity. With Kaishan's global service network and proven reliability, this compressor is engineered to reduce downtime and lower total cost of ownership. Experience unmatched power and efficiency in a compact, towable package designed for the most demanding environments.
Technical Specifications
| Model | LGCY-27/25-29/18 |
| Free Air Delivery | 27 m³/min at 25 bar, 29 m³/min at 18 bar |
| Working Pressure | 25 bar / 18 bar |
| Engine | Cummins or Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 4,500 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
25 bar / 18 bar
Free Air Delivery
27 m³/min at 25 bar, 29 m³/min at 18 bar
Weight
4,500 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
Dual pressure capability: 27 m³/min at 25 bar and 29 m³/min at 18 bar for versatile operation
Powered by reliable Cummins or Yuchai diesel engine for fuel efficiency and durability
Advanced screw airend technology ensures high efficiency and low maintenance
Intelligent control system with automatic protection and easy diagnostics
Heavy-duty cooling system for reliable performance in high ambient temperatures
Robust towable chassis with torsion-resistant design for safe highway towing
Applications
📍 Water Well Drilling
High-pressure air is essential for deep water well drilling, where consistent flow and pressure are critical for removing cuttings and driving down-the-hole hammers.
Solution: The LGCY-27/25-29/18 delivers 27 m³/min at 25 bar, providing ample power for deep drilling. Its dual pressure setting allows adjustment for different drilling depths and formations, maximizing efficiency.
📍 Mining Exploration
Mining operations require reliable, high-volume air for exploration drilling, blasting, and ventilation in remote locations.
Solution: With its rugged construction and fuel-efficient diesel engine, this compressor operates continuously in harsh environments. The 29 m³/min at 18 bar setting is ideal for large-diameter blast hole drilling.
📍 Construction Projects
Construction sites often need portable air power for pneumatic tools, concrete breaking, and foundation work.
Solution: The towable chassis and dual pressure output make it easy to transport and adapt to various tools. It provides consistent air supply for multiple pneumatic devices simultaneously.
📍 Oil and Gas Pipeline Testing
Pipeline testing requires high-pressure air for pigging, pressure testing, and drying operations.
Solution: The LGCY-27/25-29/18 offers precise pressure control and high flow, ensuring efficient pipeline maintenance. Its oil-free air output prevents contamination in sensitive operations.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-27/25-29/18This model | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins or Yuchai)
- Screw airend
- Intelligent control panel
- Oil separator tank
- Air cooler and oil cooler
- Heavy-duty air filter
- Towing chassis with brakes
- Fuel tank
Working Principle
The Kaishan LGCY-27/25-29/18 operates on the principle of rotary screw compression. A diesel engine drives the male and female rotors inside the airend. As the rotors mesh, they trap air and progressively reduce its volume, increasing pressure. Oil is injected into the compression chamber to lubricate, seal, and cool the process. The compressed air then passes through a separator to remove oil, a cooler to reduce temperature, and a filter to ensure cleanliness. The intelligent control system monitors pressure, temperature, and engine parameters, automatically adjusting the engine speed and compressor load to match demand. This ensures optimal fuel efficiency and prevents overpressure. The dual pressure capability is achieved by adjusting the control valve settings, allowing the operator to select between 25 bar and 18 bar based on application requirements. The entire process is contained within a sound-attenuated enclosure, reducing noise and protecting components from dust and weather.
Detailed Features
- ▸Dual pressure output for flexible application
- ▸High efficiency screw airend
- ▸Fuel-efficient diesel engine
- ▸Advanced microprocessor control
- ▸High ambient temperature cooling system
- ▸Large fuel tank for extended runtime
- ▸Robust towable chassis
- ▸Comprehensive safety protections
Packaging & Shipping
Each Kaishan LGCY-27/25-29/18 compressor is shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and desiccant to prevent moisture damage during ocean transport. We offer flexible shipping terms: FOB, CIF, or DDP. Delivery time is typically 30-45 days after order confirmation, depending on destination. Major ports include Shanghai, Ningbo, or Qingdao. For urgent orders, expedited shipping can be arranged. All units are inspected and photographed before loading, and complete documentation (B/L, CO, packing list) is provided for smooth customs clearance.
After-Sales Service
Kaishan provides a 12-month warranty or 2000 operating hours (whichever comes first) on the LGCY-27/25-29/18. Our global service network offers 24/7 technical support via phone or email. We provide free training for operators and maintenance staff, either on-site or at our factory. Genuine spare parts are available from regional warehouses, ensuring quick delivery. Our engineers can assist with installation, commissioning, and troubleshooting. Extended warranty and preventive maintenance contracts are available upon request. Customer satisfaction is our priority, and we strive to minimize downtime with rapid response and expert service.
Frequently Asked Questions
What are the free air delivery and working pressure of the LGCY-27/25-29/18?+
The LGCY-27/25-29/18 delivers 27 m³/min at 25 bar and 29 m³/min at 18 bar. This dual pressure capability covers high-pressure and high-flow drilling demand. The air outlet ports are G1.5×1 and G3/4×1.
What engine powers the LGCY-27/25-29/18 diesel screw compressor?+
The LGCY-27/25-29/18 is powered by a Cummins or Yuchai diesel engine. The unit weighs 4,500 kg and measures 3,800 × 1,800 × 2,500 mm. It is built on a robust towable chassis with a torsion-resistant design for safe highway towing.
Which drilling equipment can run on the LGCY-27/25-29/18 air supply?+
With 27 m³/min at 25 bar and 29 m³/min at 18 bar, the LGCY-27/25-29/18 supplies air for DTH hammers and button bits in high-demand drilling. The G1.5×1 and G3/4×1 outlet ports connect to standard drilling tool lines. Match the hammer air consumption to the selected pressure setting.
What applications suit the LGCY-27/25-29/18 portable diesel compressor?+
The LGCY-27/25-29/18 suits water well drilling, mining exploration, construction projects, and oil and gas pipeline testing. Its towable chassis and heavy-duty cooling system support operation in remote locations and high ambient temperatures. The dual pressure output allows flexible use across these job sites.
How is the LGCY-27/25-29/18 packaged and shipped?+
Each LGCY-27/25-29/18 is shipped in a protective wax coating and fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and desiccant to prevent moisture damage during ocean transport. Shipping terms include FOB, CIF, or DDP, with delivery typically 30-45 days after order confirmation.
What warranty and after-sales support come with the LGCY-27/25-29/18?+
Kaishan provides a 12-month warranty or 2000 operating hours, whichever comes first, on the LGCY-27/25-29/18. The global service network offers 24/7 technical support via phone or email. Free operator and maintenance training is available on-site or at the factory, and genuine spare parts ship from regional warehouses.
What maintenance features does the LGCY-27/25-29/18 offer?+
The LGCY-27/25-29/18 uses a high-efficiency screw airend and an advanced microprocessor control system with automatic protection and easy diagnostics. A heavy-duty cooling system supports reliable performance in high ambient temperatures. A large fuel tank allows extended runtime on site.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 27 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 18 bar / 27 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 18 bar / 27 m³/min · 115–254 mm
