Kaishan LGCY-26/25K Portable Diesel Screw Air Compressor
Model: LGCY-26/25K
The Kaishan LGCY-26/25K portable diesel screw air compressor delivers 26 m³/min of free air at 25 bar working pressure, making it a powerful solution for heavy-duty industrial applications. Built with a robust diesel engine and advanced screw airend technology, this unit ensures reliable performance in the most demanding environments, from mining and quarrying to construction and oil & gas. Its compact design and mobility allow easy transport between job sites, while the intelligent control system optimizes fuel efficiency and reduces operating costs. With a focus on durability and ease of maintenance, the LGCY-26/25K is engineered to maximize uptime and productivity. Whether you need high-pressure air for drilling, sandblasting, or pneumatic tools, this compressor delivers consistent, oil-free air quality. Backed by Kaishan's global service network, it's a smart investment for professionals seeking a dependable, high-output portable compressor.
Technical Specifications
| Model | LGCY-26/25K |
| Free Air Delivery | 26 m³/min (918 CFM) |
| Working Pressure | 25 bar (362 psi) |
| Engine | Cummins / Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 4,500 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
25 bar (362 psi)
Free Air Delivery
26 m³/min (918 CFM)
Weight
4,500 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 26 m³/min (918 CFM) for demanding applications
Working pressure of 25 bar (362 psi) suitable for deep drilling and high-pressure tools
Fuel-efficient diesel engine (Cummins/Yuchai) with advanced control system
Durable screw airend designed for continuous heavy-duty operation
Sound-attenuated enclosure reduces noise for operator comfort
Easy maintenance access with large service doors and diagnostic system
Compact and mobile design for easy transport between job sites
Global service and spare parts support from Kaishan
Applications
📍 Mining and Quarrying
High-pressure air is essential for drilling blast holes and operating pneumatic tools in mining operations.
Solution: The LGCY-26/25K provides consistent 25 bar air to power rock drills and ensure efficient blasting, increasing productivity.
📍 Water Well Drilling
Deep water well drilling requires large volumes of high-pressure air to drive down-the-hole hammers.
Solution: With 26 m³/min at 25 bar, this compressor delivers the necessary air to drill deep wells quickly and reliably.
📍 Construction
Construction sites often need compressed air for sandblasting, concrete breaking, and powering pneumatic tools.
Solution: The LGCY-26/25K's high output supports multiple tools simultaneously, reducing downtime and boosting efficiency.
📍 Oil and Gas
Oil and gas exploration and pipeline testing require high-pressure air for various processes.
Solution: This compressor's robust design and high pressure make it ideal for demanding oilfield applications, ensuring reliable operation.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-26/25KThis model | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-17/18-18/15T | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine (Cummins/Yuchai)
- Screw airend
- Air inlet valve
- Oil separator tank
- Cooling system (radiator and fan)
- Control panel with digital display
- Air filter and oil filter
- Discharge valve and piping
Working Principle
The Kaishan LGCY-26/25K operates on the principle of positive displacement using a rotary screw mechanism. Two intermeshing helical screws (rotors) rotate within a precision-machined housing. As the rotors turn, air is drawn in through an inlet valve and trapped between the screw threads. As the rotors continue to rotate, the volume of the trapped air decreases, compressing it to the desired pressure. The compressed air then passes through a separator to remove oil and contaminants, and is cooled before being discharged. The diesel engine drives the airend via a coupling or belt, and the control system regulates engine speed and compressor load to match air demand, optimizing fuel efficiency. This continuous process ensures a steady supply of compressed air with minimal pulsation, making screw compressors ideal for high-demand applications.
Detailed Features
- ▸High-pressure capability up to 25 bar
- ▸Large air delivery of 26 m³/min
- ▸Fuel-efficient diesel engine
- ▸Advanced electronic control system
- ▸Durable and reliable screw airend
- ▸Sound-attenuated canopy
- ▸Easy maintenance access
- ▸Mobile design with towbar and wheels
Packaging & Shipping
The Kaishan LGCY-26/25K is typically shipped in a protective wax coating and securely fastened onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and moisture barriers to prevent damage during transit. Delivery time is approximately 30-45 days after order confirmation, depending on destination. We ship from major Chinese ports such as Shanghai or Ningbo. For urgent orders, expedited shipping options are available. All units are inspected and tested before shipment to ensure they meet quality standards.
After-Sales Service
Kaishan offers comprehensive after-sales service for the LGCY-26/25K, including a 12-month warranty or 2000 operating hours (whichever comes first) covering major components. Our global service network provides 24-hour technical support and rapid response for spare parts. We offer on-site training for operators and maintenance personnel to ensure proper use and care of the equipment. Genuine Kaishan spare parts are readily available through our distribution centers, minimizing downtime. Additionally, we provide regular maintenance reminders and remote diagnostics through our control system to help you maximize the lifespan of your compressor.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-26/25K?+
The LGCY-26/25K delivers a free air delivery of 26 m³/min (918 CFM) at a working pressure of 25 bar (362 psi). This combination supports high-pressure air demand in demanding applications. The air outlet ports are G1.5×1 and G3/4×1.
What engine powers the LGCY-26/25K?+
The LGCY-26/25K uses a Cummins or Yuchai diesel engine. The diesel engine drives the screw airend for continuous heavy-duty operation. The unit weighs 4,500 kg with dimensions of 3,800 × 1,800 × 2,500 mm.
What equipment can the LGCY-26/25K supply air to?+
With 26 m³/min (918 CFM) at 25 bar (362 psi), the LGCY-26/25K supplies air for DTH hammers and high-pressure pneumatic tools. The G1.5×1 and G3/4×1 air outlet ports connect to the air line. It is suited to equipment requiring high-pressure air supply.
What applications is the LGCY-26/25K suitable for?+
The LGCY-26/25K is used in mining and quarrying, water well drilling, construction, and oil and gas. Its 26 m³/min (918 CFM) free air delivery and 25 bar (362 psi) working pressure support deep drilling and high-pressure tools. The compact and mobile design allows transport between job sites.
How is the LGCY-26/25K packaged and shipped?+
The LGCY-26/25K is typically shipped in a protective wax coating and secured onto a flat rack or in a 40-foot container, depending on configuration. Standard packaging includes shock-absorbing materials and moisture barriers. Delivery time is approximately 30-45 days after order confirmation, depending on destination.
What after-sales service is available for the LGCY-26/25K?+
Kaishan offers a 12-month warranty or 2000 operating hours (whichever comes first) covering major components of the LGCY-26/25K. The global service network provides 24-hour technical support and rapid response for spare parts. On-site training for operators and maintenance personnel is also offered.
What are the dimensions and weight of the LGCY-26/25K?+
The LGCY-26/25K measures 3,800 × 1,800 × 2,500 mm (L×W×H) and weighs 4,500 kg. The compact and mobile design with towbar and wheels allows easy transport between job sites. A sound-attenuated canopy reduces noise for operator comfort.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 26 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 25 bar / 26 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 25 bar / 26 m³/min · 115–254 mm
