Kaishan LGCY-17/18-18/15T Diesel Screw Compressor
Model: LGCY-17/18-18/15T
The Kaishan LGCY-17/18-18/15T portable diesel screw compressor delivers up to 17 m³/min of free air at 18 bar, making it a powerful solution for high-pressure drilling and industrial applications. Powered by a reliable diesel engine, this two-stage screw compressor combines high output with fuel efficiency, ensuring dependable performance in remote locations. Its rugged chassis and weather-resistant canopy allow operation in harsh environments, while advanced control systems simplify monitoring and maintenance. Ideal for water well drilling, mining, and construction, the LGCY-17/18-18/15T offers the durability and productivity that professionals demand. With Kaishan's global service network and genuine parts support, you can trust this compressor to keep your projects running smoothly.
Technical Specifications
| Model | LGCY-17/18-18/15T |
| Free Air Delivery | 17 m³/min (600 CFM) |
| Working Pressure | 18 bar (261 psi) |
| Engine | Cummins or Yuchai diesel engine |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 3,500 kg |
| Dimension (L×W×H) | 3,800 × 1,800 × 2,500 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
18 bar (261 psi)
Free Air Delivery
17 m³/min (600 CFM)
Weight
3,500 kg
Dimension (L×W×H)
3,800 × 1,800 × 2,500 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High free air delivery of 17 m³/min (600 CFM) at 18 bar working pressure
Two-stage screw airend for efficient high-pressure operation
Reliable diesel engine with low fuel consumption
Advanced electronic control system with auto shutdown protection
Heavy-duty air filtration for extended component life
Weather-resistant canopy and skid-mounted design for outdoor use
Applications
📍 Water Well Drilling
High-pressure air is essential for DTH hammer drilling in water well projects.
Solution: The LGCY-17/18-18/15T provides consistent 18 bar pressure to drive DTH hammers efficiently, ensuring fast penetration and reduced drilling costs.
📍 Mining and Quarrying
Mining operations require reliable air power for drilling blast holes and powering pneumatic tools.
Solution: With 17 m³/min capacity, this compressor supports multiple pneumatic tools simultaneously, boosting productivity in open-pit and underground mines.
📍 Construction
Construction sites often need portable air for pneumatic breakers, rock drills, and sandblasting.
Solution: The rugged design and easy mobility of the LGCY-17/18-18/15T make it ideal for tough construction environments, delivering dependable air power.
📍 Pipeline Testing
Pipeline integrity testing requires high-pressure air for pigging and pressure testing.
Solution: This compressor's high pressure and flow rate ensure efficient pipeline cleaning and testing, meeting industry standards.
LGCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| LGCY-17/18-18/15TThis model | LGCY-17/18-18/15T | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-17/18-18/15TK | LGCY-17/18-18/15TK | 17 m³/min (600 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-15/18-17/12T | LGCY-15/18-17/12T | — | — | — | — | Get a Quote | |
| LGCY-19/21-21/18 | LGCY-19/21-21/18 | 21 m³/min (740 CFM) at 18 bar / 19 m³/min (670 CFM) at 21 bar | 18 bar (261 psi) / 21 bar (305 psi) | Cummins or Yuchai diesel engine, 6-cylinder, turbocharged | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18X | LGCY-19/21-21/18X | 21 m³/min (740 CFM) | 18 bar (261 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18 | LGCY-23/23-25/18 | 23 m³/min | 18 bar | Cummins / Yuchai | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-19/21-21/18K | LGCY-19/21-21/18K | 19 m³/min | 21 bar / 18 bar | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/21-23/18 | LGCY-21/21-23/18 | 21 m³/min (740 CFM) | 21 bar (305 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-21/13TK | LGCY-21/13TK | 21 m³/min (740 CFM) | 13 bar (190 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-23/23-25/18K | LGCY-23/23-25/18K | 23 m³/min (812 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine | G1.5 × 1, G3/4 × 1 | Get a Quote | |
| LGCY-25/23-27/18K | LGCY-25/23-27/18K | 25 m³/min (883 CFM) | 23 bar (334 psi) | Cummins / Yuchai diesel engine, 18K series | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-26/25 | LGCY-26/25 | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-26/25K | LGCY-26/25K | 26 m³/min (918 CFM) | 25 bar (362 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-25/10TK | LGCY-25/10TK | 25 m³/min (883 CFM) | 10 bar (145 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-27/25-29/18 | LGCY-27/25-29/18 | 27 m³/min at 25 bar, 29 m³/min at 18 bar | 25 bar / 18 bar | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25 | LGCY-33/25 | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-33/25K | LGCY-33/25K | 33 m³/min (1,165 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G3/4×1 | Get a Quote | |
| LGCY-30/8TK | LGCY-30/8TK | 30 m³/min (1060 CFM) | 8 bar (116 psi) | Cummins / Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25 | LGCY-39/25 | 39 m³/min (1,377 CFM) | 25 bar (362 psi) | Cummins or Yuchai heavy-duty diesel | G1.5×1, G3/4×1 | Get a Quote | |
| LGCY-39/25A | LGCY-39/25A | 39 m³/min | 25 bar | Cummins / Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LCGC-29/23 (crawler base) | LCGC-29/23 (crawler base) | 29 | 2.3 | — | G2×1, G³/₄×1 | Get a Quote | |
| LGCY-45/25-37/35V | LGCY-45/25-37/35V | 45 m³/min (1,590 CFM) | 25 bar (362 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35 | LGCY-33/35 | 33 m³/min (1,165 CFM) | 35 bar (507 psi) | Cummins or Yuchai diesel engine | G2×1, G1×1 | Get a Quote | |
| LGCY-33/35A | LGCY-33/35A | 33 m³/min (1,165 CFM) | 35 bar (508 psi) | Cummins or Yuchai diesel engine | G1.5×1, G3/4×1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Two-stage screw airend
- Diesel engine
- Air filter
- Oil separator
- Cooling system (intercooler and aftercooler)
- Electronic control panel
- Safety valves
- Skid-mounted chassis with canopy
Working Principle
The Kaishan LGCY-17/18-18/15T operates on the principle of positive displacement screw compression. Air is drawn through a heavy-duty filter into the first-stage screw airend, where two intermeshing rotors compress the air. The compressed air then passes through an intercooler to reduce its temperature before entering the second-stage airend for further compression to the final 18 bar pressure. After the second stage, the air goes through an aftercooler and moisture separator to remove condensate. The diesel engine drives the airend via a coupling or belt system, and an electronic control unit monitors and adjusts engine speed and compressor load to match air demand, optimizing fuel efficiency. A safety valve and automatic shutdown system protect the compressor from overheating, overpressure, and low oil pressure, ensuring reliable operation.
Detailed Features
- ▸High pressure 18 bar for DTH drilling
- ▸Large air delivery 17 m³/min
- ▸Two-stage compression for efficiency
- ▸Fuel-efficient diesel engine
- ▸Advanced electronic monitoring
- ▸Weatherproof canopy for outdoor use
- ▸Easy maintenance access
- ▸Global service support
Packaging & Shipping
The Kaishan LGCY-17/18-18/15T is shipped in a protective skid-mounted package suitable for sea transport. It is typically loaded into a 40-foot container or flat rack, depending on configuration. Delivery time is approximately 30-45 days after order confirmation. Ports of shipment include Shanghai or Ningbo, China. Custom packaging and shipping arrangements can be made upon request.
After-Sales Service
Kaishan offers a comprehensive warranty of 12 months or 2000 hours (whichever comes first) for the LGCY-17/18-18/15T. Our global service network provides 24-hour technical support and genuine spare parts delivery. We also offer on-site training for operators and maintenance personnel to ensure optimal performance and safety. With service centers in over 100 countries, Kaishan ensures minimal downtime and maximum productivity for your operations.
Frequently Asked Questions
What is the free air delivery and working pressure of the LGCY-17/18-18/15T?+
The LGCY-17/18-18/15T delivers a free air delivery of 17 m³/min (600 CFM) at a working pressure of 18 bar (261 psi). These figures make it suitable for high-pressure DTH drilling. The two-stage screw airend supports operation at this pressure and flow.
What engine powers the LGCY-17/18-18/15T?+
The LGCY-17/18-18/15T is powered by a Cummins or Yuchai diesel engine. The diesel engine is matched to the two-stage screw airend for fuel-efficient operation. An advanced electronic control system monitors pressure, temperature and engine speed.
What equipment can the LGCY-17/18-18/15T power?+
With 17 m³/min (600 CFM) at 18 bar (261 psi), the LGCY-17/18-18/15T is designed to power down-the-hole (DTH) hammers and other demanding pneumatic tools. The air outlet ports are G1.5×1 and G3/4×1. The high working pressure supports DTH drilling in water well, mining and quarrying work.
What applications is the LGCY-17/18-18/15T suitable for?+
The LGCY-17/18-18/15T is used for water well drilling, mining and quarrying, construction, and pipeline testing. Its weather-resistant canopy and skid-mounted design allow outdoor operation. The heavy-duty air filtration supports extended component life in these applications.
How is the LGCY-17/18-18/15T packaged and shipped?+
The LGCY-17/18-18/15T is shipped in a protective skid-mounted package suitable for sea transport. It is typically loaded into a 40-foot container or flat rack, depending on configuration. Ports of shipment include Shanghai or Ningbo, China, with delivery time approximately 30-45 days after order confirmation.
What warranty and after-sales support come with the LGCY-17/18-18/15T?+
The LGCY-17/18-18/15T carries a warranty of 12 months or 2000 hours, whichever comes first. Kaishan's global service network provides 24-hour technical support and genuine spare parts delivery. On-site training for operators and maintenance personnel is also offered.
What are the dimensions and weight of the LGCY-17/18-18/15T?+
The LGCY-17/18-18/15T measures 3,800 × 1,800 × 2,500 mm (L×W×H) and weighs 3,500 kg. The skid-mounted design and weather-resistant canopy support outdoor use. These dimensions suit transport in a 40-foot container or flat rack.
Related Insights
Related Projects
Where This Machine Is Used
Is This Rig Right for My Project?
Answer seven questions about your hole, depth and rock — get a matched rig, compressor, hammer, bit and rod.
Compatible Drilling Rigs
Rigs this air supply can drive, matched on air demand and working pressure.
Best air-supply match shown first — the rest are still compatible.
Top matches
KG420B
- Hole range
- 90–130 mm
- Drilling depth
- 25 m
- Air demand
- 10–17 m³/min
Show 3 more compatible rigs(Other compatible rigs)
KQLG-115
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 12–25 m³/min
KG520
- Hole range
- 105–152 mm
- Drilling depth
- 25 m
- Air demand
- 15–22 m³/min
KG430
- Hole range
- 90–152 mm
- Drilling depth
- 25 m
- Air demand
- 13–20 m³/min
Marked “lower range only” means the rig's upper air demand exceeds this unit's 17 m³/min, so it works with smaller hole sizes or a second compressor.
Need Technical Support?
Request information and get a quote from our engineers.
Recommended System
Rig + air compressor + drilling tools matched to your project. Get pre-matching advice from our engineers.
Recommended Equipment Configuration
Matched from real machine parameters — rig, compressor, hammer, bit and rod working as one system.
KG550
- Hole range
- 115–254 mm
Why matched
Covers the lower range of the required 15 bar / 35 m³/min air demand — this unit is rated 18 bar / 17 m³/min, so pair it with smaller hole sizes or add a second compressor.
K8
- Hole range
- 195–254
- Air flow
- 12–31 m³/min
- Working pressure
- 10+ bar
- Bit shank
- K8** / COP84/DHD380
Why matched
Hole range 195–254 mm covers your requirement 115–254 mm.
K6
- Hole range
- 152–300
- Pressure class
- 高风压 (High pressure)
Why matched
Hole range 152–300 mm covers your requirement 115–254 mm.
76mm Drill Rods
- Rod spec
- Φ76 / Φ89 / Φ102 mm
Why matched
Matches the rig's official rod specification Φ76 / Φ89 / Φ102 mm.
System requirement: 18 bar / 17 m³/min · 115–254 mm
