Kaishan KSCY-550/13 Diesel Screw Air Compressor
Model: KSCY-550/13
The Kaishan KSCY-550/13 is a heavy-duty diesel screw air compressor engineered for continuous operation in mining, water well drilling, and construction. It delivers 550 CFM (15.6 m³/min) free air delivery at 13 bar (188 psi) working pressure, powered by a reliable diesel engine for off-grid performance. Its robust rotary screw airend, advanced cooling system, and integrated control panel ensure stable compressed air supply in harsh environments. With a compact footprint and durable chassis, this portable compressor is ideal for powering pneumatic tools, DTH hammers, and drilling rigs. The KSCY-550/13 combines fuel efficiency, low maintenance, and long service life, making it a cost-effective solution for demanding industrial applications worldwide.
Best For
Technical Specifications
| Model | KSCY-550/13 |
| Free Air Delivery | 550 CFM (15.6 m³/min) |
| Working Pressure | 13 bar (188 psi) |
| Engine | Cummins QSB5.9 or equivalent, 132 kW |
| Air Outlet Port | 2 × 3/4" or 1 × 1" |
| Weight | 2200 kg |
| Dimension (L×W×H) | 3200 × 1500 × 2200 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
13 bar (188 psi)
Free Air Delivery
550 CFM (15.6 m³/min)
Weight
2200 kg
Dimension (L×W×H)
3200 × 1500 × 2200 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
550 CFM free air delivery at 13 bar working pressure
Fuel-efficient diesel engine for off-grid operation
Heavy-duty rotary screw airend with long service life
Advanced cooling system for extreme climates
Intelligent control panel with auto shutdown protection
Compact and portable design with towbar chassis
Applications
📍 Mining & Quarrying
Powers DTH hammers, rock drills, and pneumatic tools in open-pit and underground mines.
Solution: The KSCY-550/13 provides consistent high-pressure air to maximize drilling efficiency and reduce downtime.
📍 Water Well Drilling
Supports down-the-hole hammer drilling for water wells in remote areas.
Solution: Its reliable diesel engine and 13 bar pressure ensure effective hammer operation without grid power.
📍 Construction & Civil Engineering
Operates pneumatic breakers, sandblasters, and concrete sprayers on construction sites.
Solution: Portable design and robust performance deliver air power where needed, enhancing productivity.
📍 Emergency & Industrial Backup
Provides temporary compressed air for plant shutdowns, pipeline testing, and emergency repairs.
Solution: Quick deployment and automatic controls ensure immediate air supply in critical situations.
KSCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| KSCY-550/13This model | KSCY-550/13 | 550 CFM (15.6 m³/min)★ | 13 bar (188 psi) | Cummins QSB5.9 or equivalent, 132 kW | 2 × 3/4" or 1 × 1" | Get a Quote | |
| KSCY-400/14.5K | KSCY-400/14.5K | 400 CFM (11.3 m³/min) | 14.5 bar (210 psi) | Diesel engine, 6-cylinder, 110 kW | 2 × 3/4 inch or 1 × 1 inch | Get a Quote | |
| KSCY-220/8X | KSCY-220/8X | 22 m³/min | 8 bar (116 psi) | Weichai/Deutz diesel, 75-90 kW | G1.5×1, G3/4×1 | Get a Quote | |
| KSCY-175/8 | KSCY-175/8 | 5.0 m³/min (175 CFM) | 8 bar (116 psi) | Cummins / Yuchai, 52 kW (70 HP) | G1-1/4 × 1, G3/4 × 1 | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine
- Rotary screw airend
- Air-oil separator tank
- Cooling system (radiator and fan)
- Intake air filter
- Control panel
- Discharge valve
- Chassis with towbar
Working Principle
The Kaishan KSCY-550/13 operates on the rotary screw principle. A diesel engine drives the airend, where two intermeshing helical screws rotate. As the screws turn, air is trapped between the lobes and the casing, and as the space decreases, the air is compressed. Oil is injected into the compression chamber to lubricate, seal, and cool the process. The compressed air-oil mixture then passes through a separator, where oil is removed and returned to the system, while clean air exits through the discharge valve. The intelligent control system monitors pressure and temperature, adjusting engine speed to match demand, ensuring efficient fuel use. This continuous process delivers a steady flow of compressed air at the required pressure for demanding applications.
Detailed Features
- ▸High efficiency rotary screw airend
- ▸Fuel-efficient diesel engine
- ▸Advanced cooling system
- ▸Intelligent control panel
- ▸Heavy-duty air filtration
- ▸Compact and portable design
- ▸Automatic shutdown protection
- ▸Easy maintenance access
Packaging & Shipping
The Kaishan KSCY-550/13 is shipped in a protective wrap or wooden crate, depending on customer requirements. It is loaded into a 20ft or 40ft container for sea freight. Standard delivery time is 30-45 days after order confirmation. Ports of shipment include Shanghai or Ningbo, China. Custom packaging and shipping arrangements are available upon request.
After-Sales Service
Kaishan offers a 12-month warranty on the KSCY-550/13. Our global service network provides 24-hour technical support and genuine spare parts. We offer on-site training for operators and maintenance staff. Regular maintenance kits and consumables are available for quick delivery. Our team ensures minimal downtime and optimal performance throughout the product's life.
Frequently Asked Questions
What free air delivery and working pressure does the KSCY-550/13 provide?+
The KSCY-550/13 delivers 550 CFM (15.6 m³/min) of free air delivery at a working pressure of 13 bar (188 psi). These figures suit continuous high-demand air supply. The air outlet port is available as 2 × 3/4" or 1 × 1".
What engine powers the KSCY-550/13?+
The KSCY-550/13 is powered by a Cummins QSB5.9 or equivalent diesel engine rated at 132 kW. The diesel engine allows off-grid operation in remote locations without access to grid power.
Can the KSCY-550/13 run DTH hammers and drilling rigs?+
Yes, the KSCY-550/13 supplies 550 CFM (15.6 m³/min) at 13 bar (188 psi), which is intended for powering DTH hammers, drilling rigs and pneumatic tools. It is used in mining and quarrying, water well drilling, and construction and civil engineering.
Is the KSCY-550/13 suitable for remote sites and harsh climates?+
The KSCY-550/13 is a portable diesel unit built for off-grid operation, with an advanced cooling system for extreme climates and an intelligent control panel with automatic shutdown protection. Its compact and portable design uses a towbar chassis, and the unit weighs 2200 kg with dimensions of 3200 × 1500 × 2200 mm.
What maintenance access and protection features does the KSCY-550/13 have?+
The KSCY-550/13 offers easy maintenance access, heavy-duty air filtration and automatic shutdown protection. The intelligent control panel provides real-time monitoring with automatic shutdown protection, and the heavy-duty rotary screw airend is designed for long service life.
How is the KSCY-550/13 packaged and shipped?+
The KSCY-550/13 is shipped in a protective wrap or wooden crate, depending on customer requirements, and is loaded into a 20ft or 40ft container for sea freight. Standard delivery time is 30-45 days after order confirmation, with shipment from Shanghai or Ningbo, China.
What warranty and after-sales support come with the KSCY-550/13?+
Kaishan offers a 12-month warranty on the KSCY-550/13. A global service network provides 24-hour technical support and genuine spare parts, along with on-site training for operators and maintenance staff.
