Kaishan KSCY-220/8X Portable Diesel Screw Air Compressor
Model: KSCY-220/8X
The Kaishan KSCY-220/8X is a robust portable diesel screw air compressor delivering 22 m³/min of free air at 8 bar, engineered for heavy-duty drilling and construction applications. This mobile compressor combines high-efficiency screw airend, reliable diesel engine, and intelligent control system to ensure continuous operation in the most demanding environments. With its rugged chassis and towing design, the KSCY-220/8X offers exceptional mobility and quick setup on site. Ideal for quarry drilling, water well drilling, and pipeline construction, it provides stable air flow to power DTH hammers and pneumatic tools. Backed by Kaishan's global service network, this compressor guarantees low operating costs and long service life, making it a trusted choice for contractors worldwide.
Technical Specifications
| Model | KSCY-220/8X |
| Free Air Delivery | 22 m³/min |
| Working Pressure | 8 bar (116 psi) |
| Engine | Weichai/Deutz diesel, 75-90 kW |
| Air Outlet Port | G1.5×1, G3/4×1 |
| Weight | 2,800 kg |
| Dimension (L×W×H) | 3600×1800×2000 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Working Pressure
8 bar (116 psi)
Free Air Delivery
22 m³/min
Weight
2,800 kg
Dimension (L×W×H)
3600×1800×2000 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
High-efficiency screw airend with low energy consumption
Rugged diesel engine with low fuel consumption and long lifespan
Integrated microprocessor controller for automatic monitoring and protection
Sound-attenuated canopy for reduced noise levels (below 75 dB(A))
Heavy-duty towable chassis with high ground clearance for off-road mobility
Large-capacity fuel tank for extended operation (up to 12 hours)
Applications
📍 Quarry Drilling
Provides high-pressure air for DTH hammers in granite, limestone, and marble quarries.
Solution: The KSCY-220/8X delivers consistent 8 bar pressure and 22 m³/min flow, ensuring efficient penetration and chip removal, reducing drilling cost per meter.
📍 Water Well Drilling
Supports reverse circulation drilling rigs for water well construction in various geological conditions.
Solution: With its high volume air, the compressor ensures stable lifting of cuttings and prevents borehole collapse, increasing drilling safety and speed.
📍 Pipeline Construction
Used for pneumatic testing, purging, and powering pneumatic tools during pipeline installation.
Solution: The compressor's reliable air supply and pressure stability help maintain testing standards and tool performance, minimizing project delays.
📍 Mining & Tunneling
Operates rock drills, shotcrete machines, and other pneumatic equipment in underground and surface mining.
Solution: The rugged design and dust-resistant filtration ensure continuous operation in harsh mining environments, enhancing productivity and worker safety.
KSCY Series Models
Compare specifications across the series to find the right model.
| ☑ | Model | Model | Free Air Delivery | Working Pressure | Engine | Air Outlet Port | Inquire |
|---|---|---|---|---|---|---|---|
| KSCY-220/8XThis model | KSCY-220/8X | 22 m³/min | 8 bar (116 psi) | Weichai/Deutz diesel, 75-90 kW | G1.5×1, G3/4×1 | Get a Quote | |
| KSCY-175/8 | KSCY-175/8 | 5.0 m³/min (175 CFM) | 8 bar (116 psi) | Cummins / Yuchai, 52 kW (70 HP) | G1-1/4 × 1, G3/4 × 1 | Get a Quote | |
| KSCY-400/14.5K | KSCY-400/14.5K | 400 CFM (11.3 m³/min) | 14.5 bar (210 psi) | Diesel engine, 6-cylinder, 110 kW | 2 × 3/4 inch or 1 × 1 inch | Get a Quote | |
| KSCY-550/13 | KSCY-550/13 | 550 CFM (15.6 m³/min) | 13 bar (188 psi) | Cummins QSB5.9 or equivalent, 132 kW | 2 × 3/4" or 1 × 1" | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Screw airend
- Diesel engine (e.g., Weichai/Deutz)
- Air intake filter
- Oil separator tank
- Minimum pressure valve
- Aftercooler with moisture separator
- Electronic controller (PLC)
- Heavy-duty towing chassis with suspension
Working Principle
The Kaishan KSCY-220/8X operates on the rotary screw compression principle. A diesel engine drives two intermeshing helical rotors inside the airend. As the rotors turn, the volume between them decreases, compressing the air drawn in through the intake filter. Oil is injected into the compression chamber to seal the gaps, lubricate the rotors, and absorb heat. The compressed air-oil mixture is discharged into a separator tank, where the oil is removed and cooled before being recirculated. The clean compressed air then passes through a minimum pressure valve and an aftercooler, reducing its temperature and condensing moisture. The final air is delivered to the outlet port at the required pressure of 8 bar. The engine speed is regulated by an electronic governor to match air demand, ensuring optimal fuel efficiency and stable output.
Detailed Features
- ▸Direct drive coupling for higher efficiency and lower maintenance
- ▸Automatic idle control when no air demand
- ▸Full instrumentation with alarm and shutdown functions
- ▸Cold start capability down to -20°C
- ▸High ambient temperature operation up to 50°C
- ▸Easy service access with wide-opening doors
- ▸Optional soundproof canopy for urban areas
- ▸Integrated lifting eyes and forklift pockets for easy handling
Packaging & Shipping
The KSCY-220/8X is exported in a standard 40-foot open-top container or flat rack, depending on dimensions and weight. The unit is securely fastened with steel wire ropes and wooden blocks to prevent movement during transit. All loose parts and toolkits are packed in a separate wooden case. The compressor is wrapped with waterproof film and anti-rust coating to protect against sea moisture. Delivery time is 30-45 days after receipt of advance payment. Shipping is available from major Chinese ports such as Shanghai, Qingdao, or Ningbo. For trailer-mounted versions, the unit can be shipped as a whole with the towing axle removed to fit container dimensions. Custom packaging and marking are available upon request.
After-Sales Service
Kaishan provides comprehensive after-sales support for the KSCY-220/8X. The compressor comes with a 12-month warranty covering manufacturing defects in materials and workmanship. Our global service network offers 24/7 technical support via phone or video call. We provide free operator training and installation guidance. Spare parts are available for quick dispatch from our central warehouse in China and regional hubs. In case of major breakdowns, our engineers can visit the site within 72 hours (depending on location). We also offer annual maintenance contracts and extended warranty options to maximize your equipment uptime.
Frequently Asked Questions
What is the free air delivery and working pressure of the KSCY-220/8X?+
The KSCY-220/8X delivers a free air delivery of 22 m³/min at a working pressure of 8 bar (116 psi). These figures apply to the portable diesel screw air compressor as specified.
What engine powers the KSCY-220/8X?+
The KSCY-220/8X is powered by a Weichai/Deutz diesel engine rated at 75-90 kW. The unit weighs 2,800 kg and measures 3600×1800×2000 mm.
What equipment can the KSCY-220/8X supply air to?+
With 22 m³/min at 8 bar, the KSCY-220/8X can supply air to DTH hammers and pneumatic tools. The air outlet ports are G1.5×1 and G3/4×1.
Where can the KSCY-220/8X be used?+
The KSCY-220/8X is suited to quarry drilling, water well drilling, pipeline construction, and mining and tunneling. Its heavy-duty towable chassis with high ground clearance supports off-road mobility.
Does the KSCY-220/8X have cold start and high ambient temperature capability?+
The KSCY-220/8X offers cold start capability down to -20°C and high ambient temperature operation up to 50°C. It also has automatic idle control when there is no air demand.
How is the KSCY-220/8X packaged for shipping?+
The KSCY-220/8X is exported in a standard 40-foot open-top container or flat rack, depending on dimensions and weight. Loose parts and toolkits are packed in a separate wooden case.
What warranty and after-sales support come with the KSCY-220/8X?+
The KSCY-220/8X comes with a 12-month warranty covering manufacturing defects in materials and workmanship. Kaishan's global service network offers 24/7 technical support via phone or video call.
