Kaishan ZT5 DTH Drilling Rig

Name: Kaishan ZT5 DTH Drilling Rig
Brand: Kaishan
SKU: ZT5
Availability: InStock

Model: ZT5

The Kaishan ZT5 DTH drilling rig is a compact, high-efficiency down-the-hole drilling solution engineered for quarrying, mining, water well and construction projects. Powered by a reliable diesel engine and optimized for DTH hammer operation, it delivers fast penetration in medium to hard rock formations. With a maximum drilling depth of 30 m and hole diameter range of 90–130 mm, the ZT5 balances productivity with maneuverability on tight job sites. Its robust track undercarriage, hydraulic boom and dust suppression system ensure stable, low-cost operation even in challenging terrain. The ZT5 is easy to transport, simple to maintain and backed by Kaishan's global service network, making it an ideal entry-level DTH rig for contractors seeking dependable performance and quick return on investment.

Best For

Quarry Blast Hole Drilling Mining Production Drilling Water Well Drilling Construction and Foundation Work

Technical Specifications

Model	Kaishan ZT5
Drilling Depth	24 m
Hole Diameter	90–105 mm
Drilling Method	Down-the-hole (DTH) hammer drilling
Engine Power	78 kW (105 hp)
Weight	13000 kg
Dimension (L×W×H)	8630 × 2,100 × 2830 mm

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan ZT5 is a track-mounted down-the-hole (DTH) drilling rig designed for small to medium-scale rock drilling operations. As part of Kaishan's well-established DTH drill rig series, the ZT5 combines a durable chassis, efficient hydraulic system and proven DTH hammer technology to deliver reliable performance in quarrying, mining, water well and foundation work. Its compact footprint and moderate weight make it easy to transport between sites, while the powerful diesel engine ensures sufficient torque and feed force for demanding rock conditions. ## Technical Features The ZT5 is built around a high-torque rotary head and a heavy-duty feed chain that work together with a DTH hammer to achieve fast penetration rates. The hydraulic boom and guide shell allow precise positioning of the drill hole, reducing setup time. A standard dust collector keeps the working environment cleaner and extends component life. The track undercarriage provides excellent stability on uneven ground, and the centralized control panel simplifies operation for less experienced operators. With a drilling depth of up to 30 m and hole diameters from 90 to 130 mm, the ZT5 covers a wide range of typical DTH applications. ## Applications The ZT5 excels in quarry blast hole drilling, where its speed and accuracy improve fragmentation and reduce overall drilling cost. In mining, it is used for short-hole production and auxiliary drilling. For water well projects, the ZT5 can drill shallow to medium-depth wells in unconsolidated and hard rock formations. It is also suitable for construction sites requiring rock anchors, foundation holes or site preparation. Its ability to operate in confined spaces makes it a practical choice for urban construction and road building projects. ## Why Choose Kaishan ZT5 Kaishan has decades of experience in rock drilling equipment, and the ZT5 reflects this heritage through robust construction, easy maintenance and readily available spare parts. The rig is designed for low operating cost, with a fuel-efficient engine and long-life consumables. Whether you are a contractor expanding your fleet or a quarry owner looking for a reliable entry-level DTH rig, the ZT5 offers an excellent balance of price and performance. Backed by Kaishan's global service network, the ZT5 is a smart investment for your drilling business.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Hole Diameter

90–105 mm

Drilling Depth

24 m

Engine Power

78 kW (105 hp)

Weight

13000 kg

Dimension (L×W×H)

8630 × 2,100 × 2830 mm

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Compact track-mounted design for easy transport and maneuverability

✓

Optimized for DTH hammer drilling in medium to hard rock

✓

Maximum drilling depth of 30 m and hole diameter of 90–130 mm

✓

Reliable diesel engine with high torque for demanding conditions

✓

Hydraulic boom and guide shell for precise hole positioning

✓

Integrated dust suppression system for cleaner and safer operation

✓

Robust undercarriage ensures stability on uneven terrain

✓

Simple maintenance and widely available spare parts

Applications

📍 Quarry Blast Hole Drilling

Drilling vertical and inclined blast holes in limestone, granite and other hard rock quarries.

Solution: The ZT5's DTH hammer and high feed force deliver fast penetration, improving fragmentation and reducing cost per ton.

📍 Mining Production Drilling

Short-hole drilling for ore extraction and auxiliary operations in small to medium mines.

Solution: Compact size and track mobility allow the ZT5 to work in narrow stopes and quickly move between faces.

📍 Water Well Drilling

Drilling shallow to medium-depth water wells in soil, sand, gravel and hard rock formations.

Solution: With appropriate DTH hammer and bit, the ZT5 can drill 90–130 mm wells up to 30 m deep efficiently.

📍 Construction and Foundation Work

Rock anchors, foundation holes, and site preparation for buildings, roads and bridges.

Solution: The ZT5's precise positioning and dust control make it suitable for urban job sites with strict environmental rules.

ZT Series Models

Compare specifications across the series to find the right model.

Model	Model	Drilling Depth	Hole Diameter	Drilling Method	Engine Power	Inquire
ZT5This model	Kaishan ZT5	24 m	90–105 mm	Down-the-hole (DTH) hammer drilling	78 kW (105 hp)	Get a Quote
ZT11	Kaishan ZT11	32 m	115–152 mm	DTH (Down-The-Hole) drilling	235 kW	Get a Quote
ZT12	Kaishan ZT12	32 m	115–152 mm	DTH (Down-The-Hole)	264 kW	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Diesel engine
Hydraulic pump and control valves
Rotary head
Feed chain and guide shell
Hydraulic boom
Track undercarriage
Dust collector
Control panel

Working Principle

The Kaishan ZT5 operates on the down-the-hole (DTH) drilling principle. A DTH hammer is attached to the end of the drill string, directly behind the drill bit. High-pressure air from an external air compressor is fed through the drill pipe to the hammer. Inside the hammer, the air drives a piston that strikes the bit with high-frequency impacts. Simultaneously, the rig's rotary head turns the drill string slowly, indexing the bit for the next impact. The feed system applies optimal thrust to keep the bit in contact with the rock. The air also serves to flush cuttings out of the hole through the annulus. This combination of impact, rotation and flushing achieves rapid penetration in hard rock. The ZT5's hydraulic system controls boom movement, feed and rotation, while the diesel engine provides power for the hydraulic pumps and track travel. The operator controls all functions from a centralized panel, ensuring safe and efficient drilling.

Detailed Features

▸Compact and maneuverable track chassis
▸Optimized for DTH hammer drilling
▸Max drilling depth 30 m
▸Hole diameter 90–130 mm
▸Reliable diesel engine
▸Hydraulic boom for precise positioning
▸Dust suppression system
▸Easy maintenance and spare parts availability

Packaging & Shipping

The Kaishan ZT5 DTH drilling rig is shipped in a standard export packing suitable for sea transportation. The main unit is partially disassembled to fit into a 40HQ container, with the boom and guide shell folded or removed as required. All exposed hydraulic and electrical components are protected with anti-corrosion film and wooden crates. Delivery time is typically 30–45 days after order confirmation, depending on configuration and quantity. Ports of shipment include Shanghai, Ningbo or Qingdao, China. We can also arrange FOB, CIF or DDP terms according to customer requirements.

After-Sales Service

Kaishan provides comprehensive after-sales service for the ZT5 DTH drilling rig. The rig comes with a 12-month warranty or 2000 working hours (whichever comes first) covering major components. Our global service network offers 24-hour technical support via phone or email. We provide free operator training at our factory or on-site (travel expenses may apply). Spare parts are available through our regional warehouses, ensuring quick delivery. Regular maintenance kits and consumables are also supplied to keep your rig running at peak performance. Our experienced engineers can assist with commissioning, troubleshooting and optimization for your specific drilling conditions.
