Kaishan KG920D DTH Drilling Rig

Name: Kaishan KG920D DTH Drilling Rig
Brand: Kaishan
SKU: KG920D
Availability: InStock

Model: KG920D

The Kaishan KG920D is a high-performance DTH drilling rig designed for demanding open-pit mining, quarrying, and water well projects. Built with a robust tracked undercarriage and a powerful diesel engine, this rig delivers efficient down-the-hole hammer drilling in hard rock formations. It achieves hole diameters of 90–165 mm and drilling depths up to 25 meters, making it ideal for blast hole drilling and deep foundation work. The KG920D features a high-torque rotary head, reliable dust collection system, and ergonomic operator cabin for enhanced productivity and safety. Its compact design ensures easy maneuverability on rough terrain, while the advanced hydraulic system reduces downtime and maintenance costs. Whether you are drilling in limestone, granite, or sandstone, the KG920D offers superior penetration rates and consistent performance. With global service support and readily available spare parts, this rig is a cost-effective solution for contractors seeking reliability and efficiency in drilling operations.

Best For

Open-Pit Mining Quarrying Water Well Drilling Construction Projects

Technical Specifications

Model	Kaishan KG920D
Drilling Depth	25 m
Hole Diameter	90–165 mm
Drilling Method	Down-the-Hole (DTH) Hammer Drilling
Engine Power	194 kW
Weight	12,000 kg
Dimension (L×W×H)	7,500 × 2,500 × 3,200 mm

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan KG920D is a track-mounted down-the-hole (DTH) drilling rig engineered for high-efficiency hard rock drilling. It combines a powerful diesel engine, robust hydraulic system, and advanced dust control to deliver reliable performance in mining, quarrying, and water well applications. With a drilling depth of up to 25 meters and hole diameters from 90 to 165 mm, it is perfectly suited for blast hole drilling and deep foundation projects. ## Technical Features The KG920D is equipped with a high-torque rotary head and a heavy-duty feed system that ensures smooth and fast penetration. The rig features a reliable dust collection system that minimizes environmental impact and improves operator visibility. Its ergonomic cabin provides excellent comfort and control, reducing operator fatigue during long shifts. The tracked undercarriage offers superior mobility on rough terrain, while the centralized lubrication system simplifies maintenance. Powered by a 194 kW diesel engine, the KG920D delivers ample power for demanding drilling conditions. ## Applications This DTH drilling rig is widely used in open-pit mining, quarrying, water well drilling, and construction projects. It excels in hard rock formations such as granite, limestone, and sandstone. The KG920D is also ideal for drilling blast holes, anchor holes, and drainage holes. Its versatility and reliability make it a valuable asset for contractors and mining companies worldwide. ## Why Choose Kaishan KG920D With decades of experience in drilling equipment, Kaishan has designed the KG920D to meet the highest standards of performance and durability. The rig's modular design allows for easy transportation and quick setup, while its fuel-efficient engine reduces operating costs. Backed by a global service network and comprehensive warranty, the KG920D ensures maximum uptime and productivity. Whether you are working in a remote mine site or an urban construction project, this rig delivers consistent results and exceptional value.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Hole Diameter

90–165 mm

Drilling Depth

25 m

Engine Power

194 kW

Weight

12,000 kg

Dimension (L×W×H)

7,500 × 2,500 × 3,200 mm

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Powerful 194 kW diesel engine for demanding drilling conditions

✓

Drilling depth up to 25 meters and hole diameter 90–165 mm

✓

High-torque rotary head for efficient DTH hammer drilling

✓

Advanced dust collection system for a cleaner worksite

✓

Ergonomic operator cabin with intuitive controls

✓

Tracked undercarriage for superior mobility on rough terrain

✓

Centralized lubrication system for easy maintenance

✓

Global service support and readily available spare parts

Applications

📍 Open-Pit Mining

Blast hole drilling in hard rock such as granite and limestone.

Solution: The KG920D's high penetration rate and reliable dust control ensure efficient and safe mining operations.

📍 Quarrying

Drilling blast holes for aggregate production in quarries.

Solution: With its powerful engine and durable components, the KG920D delivers consistent performance in abrasive rock conditions.

📍 Water Well Drilling

Drilling water wells in hard rock formations up to 25 meters deep.

Solution: The rig's DTH hammer system and high torque rotary head make it ideal for fast and efficient water well drilling.

📍 Construction Projects

Foundation drilling, anchor holes, and drainage holes.

Solution: The KG920D's compact design and mobility allow it to work in tight spaces and rough terrains, ensuring project timelines are met.

KG Series Models

Compare specifications across the series to find the right model.

Model	Model	Drilling Depth	Hole Diameter	Drilling Method	Engine Power	Inquire
KG920DThis model	Kaishan KG920D	25 m	90–165 mm	Down-the-Hole (DTH) Hammer Drilling	194 kW	Get a Quote
KG430	Kaishan KG430	30 m	90–165 mm	DTH (Down-The-Hole)	73 kW	Get a Quote
KG520	Kaishan KG520	30 m (single pass); 100 m (with extension rods)	90–165 mm	Down-The-Hole (DTH) drilling	194 kW (260 HP)	Get a Quote
KG590	Kaishan KG590	30 m	90–165 mm	DTH (Down-The-Hole) Hammer Drilling	194 kW (260 HP)	Get a Quote
KG590H	KG590H	25 m	105-152 mm	DTH (Down-The-Hole) Drilling	194 kW (260 HP)	Get a Quote
KG720	Kaishan KG720	30 m	90–165 mm	Down-the-Hole (DTH) Drilling	194 kW	Get a Quote
KG420B	Kaishan KG420B	25 m	90-130 mm	Down-the-Hole (DTH)	58 kW	Get a Quote
KG550	KG550	30 m	115–165 mm	DTH (Down-The-Hole) hammer drilling	73.5 kW	Get a Quote
KG940A	KG940A	30 m	90–165 mm	DTH (Down-The-Hole)	58 kW	Get a Quote
KG920A	Kaishan KG920A	25 m	90–165 mm	DTH (Down-The-Hole) Hammer	118 kW (158 hp)	Get a Quote
KG920B	KG920B	25 m	90-165 mm	DTH (Down-The-Hole)	194 kW	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Diesel engine
Hydraulic rotary head
DTH hammer and drill bit
Feed beam and chain
Tracked undercarriage
Dust collection system
Operator cabin
Control panel

Working Principle

The Kaishan KG920D operates on the down-the-hole (DTH) drilling principle, where a pneumatic hammer is located at the bottom of the drill string, directly above the drill bit. High-pressure air is supplied through the drill pipe to drive the hammer piston, which strikes the bit with high frequency and impact energy. The rotation of the drill string is provided by a hydraulic rotary head, ensuring the bit indexes between blows. The cuttings are flushed out of the hole by the exhaust air, which also helps to cool the bit. This method allows for efficient drilling in hard rock formations with minimal deviation. The KG920D's hydraulic system controls the feed force and rotation speed to optimize penetration rates, while the dust collection system captures airborne particles for a safer working environment. The entire process is managed from the operator cabin, providing precise control and real-time monitoring.

Detailed Features

▸High drilling efficiency in hard rock
▸Reliable and durable construction
▸Low fuel consumption
▸Easy maintenance and serviceability
▸Comfortable and safe operator environment
▸Excellent mobility on rough terrain
▸Advanced dust suppression
▸Global parts and service support

Packaging & Shipping

The Kaishan KG920D is shipped in a disassembled state for efficient container transport. The main components are securely packed and protected against corrosion and impact. Standard packaging includes steel frames, wooden crates, and waterproof covers. The rig can be loaded into a 40HQ container or flat rack, depending on configuration. Delivery time is typically 30–45 days after order confirmation, depending on destination and customization. Shipping ports include Shanghai, Qingdao, or as per customer request. All necessary documentation for export, including CE certification and operation manuals, is provided.

After-Sales Service

Kaishan offers comprehensive after-sales service for the KG920D, including a 12-month warranty on major components (excluding wear parts). Our global service network provides 24-hour technical support and on-site assistance. We offer operator training and maintenance workshops to ensure optimal performance. Genuine spare parts are available from regional warehouses for quick delivery. Our service team is committed to minimizing downtime and maximizing your return on investment.

Frequently Asked Questions

What hole sizes and drilling depth can the Kaishan KG920D achieve?+

The KG920D drills hole diameters from 90 to 165 mm and reaches a drilling depth of up to 25 m. It uses down-the-hole (DTH) hammer drilling for hard rock formations. This size range suits blast hole drilling and deep foundation work.

What engine powers the KG920D DTH drilling rig?+

The KG920D is powered by a 194 kW diesel engine. The rig weighs 12,000 kg and measures 7,500 × 2,500 × 3,200 mm (L×W×H). The engine drives a high-torque rotary head for DTH hammer drilling.

What air supply does the KG920D need for DTH hammer drilling?+

The KG920D is a track-mounted DTH drilling rig that operates with a DTH hammer for 90–165 mm holes to 25 m depth. Match the hammer and button bit to the 90–165 mm hole diameter range. The rig's high-torque rotary head and heavy-duty feed system support the DTH hammer during drilling.

Where can the KG920D be used?+

The KG920D is built for open-pit mining, quarrying, water well drilling and construction projects. Its tracked undercarriage provides mobility on rough terrain, and the 194 kW engine supports demanding drilling conditions. It handles hard rock such as limestone, granite and sandstone.

How is the Kaishan KG920D maintained?+

The KG920D features a centralized lubrication system for easy maintenance. A reliable dust collection system minimizes environmental impact and improves operator visibility. The ergonomic operator cabin with intuitive controls reduces operator fatigue during long shifts.

How is the KG920D shipped and what is the delivery time?+

The KG920D is shipped disassembled for efficient container transport, with steel frames, wooden crates and waterproof covers protecting the components. It can be loaded into a 40HQ container or flat rack, depending on configuration. Delivery time is typically 30–45 days after order confirmation.

What warranty and after-sales support come with the KG920D?+

Kaishan offers a 12-month warranty on major components of the KG920D, excluding wear parts. The global service network provides 24-hour technical support and on-site assistance. Operator training, maintenance workshops and genuine spare parts from regional warehouses are available.
