Kaishan L2 DTH Hammer for Water Well & Mining Drilling

Name: Kaishan L2 DTH Hammer for Water Well & Mining Drilling
Brand: Kaishan
SKU: L2
Availability: InStock

Model: L2

The Kaishan L2 DTH hammer is a low-pressure down-the-hole tool engineered for reliable performance in water well drilling, quarrying, and mining. As a core component in the Drilling Tools category, this DTH hammer delivers efficient rock penetration with optimized air consumption and durable construction. It is compatible with a range of drilling rigs and is designed for use with 2-inch drill pipes and button bits. The L2 model features a simple structure, easy maintenance, and stable operation, making it a cost-effective choice for contractors working in medium-hard rock formations. Whether you are drilling water wells, blast holes, or foundation holes, the Kaishan L2 provides consistent impact energy and long service life. Its precision-manufactured internal parts reduce wear and downtime, ensuring maximum productivity on site. Backed by Kaishan's global service network, this DTH hammer is a dependable tool for demanding drilling projects.

Best For

Water Well Drilling Mining & Quarrying Construction & Foundation Geothermal Exploration

Technical Specifications

Model	Kaishan L2
Type	Low-pressure DTH Hammer
Size	2-inch (compatible with 64-76 mm bits)
Application	Water well drilling, mining, quarrying, construction
Material	Alloy steel with heat treatment
Weight	Approx. 12 kg
Packing	Wooden case

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan L2 DTH hammer is a low-pressure down-the-hole hammer designed for efficient drilling in medium-hard to hard rock formations. As a specialized drilling tool, it converts compressed air into high-frequency impact energy, driving the drill bit into the rock while simultaneously rotating for optimal penetration. This model is widely used in water well drilling, mining, quarrying, and construction projects where reliable performance and low operating costs are essential. ## Technical Features The L2 hammer features a robust outer cylinder and a precision-machined piston that ensures smooth reciprocation and minimal energy loss. Its valveless design simplifies the structure, reduces maintenance requirements, and improves reliability in dusty and harsh environments. The hammer is compatible with standard 2-inch API drill pipes and button bits, making it easy to integrate into existing drill strings. Advanced heat treatment and high-quality alloy steel construction provide excellent wear resistance and extended service life. The optimized air passage design reduces pressure drop and improves flushing efficiency, ensuring fast hole cleaning and reduced bit wear. ## Applications This DTH hammer is ideal for water well drilling, geothermal exploration, blast hole drilling in quarries, and foundation piling. It performs well in granite, limestone, sandstone, and other medium-hard rock types. The L2 model is particularly suitable for contractors who require a balance between drilling speed and air consumption. Its compact size and lightweight design make it easy to handle and transport, while its durable construction ensures reliable operation even in remote locations. ## Why Choose Kaishan L2 Kaishan is a leading manufacturer of drilling equipment with decades of experience. The L2 hammer is produced under strict quality control and tested for performance and durability. It offers a cost-effective solution for drilling professionals who demand consistent results. With readily available spare parts and a global service network, Kaishan ensures minimal downtime and maximum productivity for your drilling operations.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

Approx. 12 kg

Model

Kaishan L2

Type

Low-pressure DTH Hammer

Size

2-inch (compatible with 64-76 mm bits)

Application

Water well drilling, mining, quarrying, construction

Material

Alloy steel with heat treatment

Packing

Wooden case

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Valveless design for simplified structure and reduced maintenance

✓

High-frequency impact energy for efficient rock penetration

✓

Compatible with 2-inch API drill pipes and standard button bits

✓

Durable alloy steel construction with advanced heat treatment

✓

Optimized air passages for effective flushing and hole cleaning

✓

Lightweight and compact for easy handling and transport

Applications

📍 Water Well Drilling

Efficiently drills water wells in medium-hard rock formations.

Solution: The L2 hammer provides reliable penetration and fast hole cleaning, reducing drilling time and cost.

📍 Mining & Quarrying

Used for blast hole drilling in open-pit mines and quarries.

Solution: Its durable construction and high impact energy ensure consistent performance in abrasive rock.

📍 Construction & Foundation

Ideal for foundation piling and anchor drilling in construction projects.

Solution: The compact design allows use in confined spaces, while the valveless mechanism ensures reliability.

📍 Geothermal Exploration

Suitable for drilling geothermal boreholes in hard rock.

Solution: Optimized air consumption and efficient flushing reduce energy costs and improve drilling speed.

Low Pressure Series Models

Compare specifications across the series to find the right model.

Model	Model	Type	Size	Application	Material	Inquire
L2This model	Kaishan L2	Low-pressure DTH Hammer	2-inch (compatible with 64-76 mm bits)	Water well drilling, mining, quarrying, construction	Alloy steel with heat treatment	Get a Quote
L2	Kaishan L2	DTH Drill Bit	110 mm (standard); other sizes available	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
L3	Kaishan L3	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, Quarrying, Water Well, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Outer cylinder
Piston
Distributor
Check valve
Drill bit shank adapter
Top sub
Bottom sub
Retainer ring

Working Principle

The Kaishan L2 DTH hammer operates on the principle of converting compressed air into mechanical impact energy. Compressed air is supplied through the drill pipe to the hammer, where it drives a piston in a reciprocating motion. The piston strikes the drill bit shank, generating a high-frequency impact wave that fractures the rock. Simultaneously, the drill string rotates slowly, indexing the bit for the next impact. After each impact, the air is exhausted through the bit holes, flushing cuttings out of the hole and cooling the bit. The valveless design of the L2 simplifies the air distribution, reducing wear and improving reliability. The hammer's internal components are precisely machined to ensure smooth operation and minimal energy loss, resulting in efficient rock breakage and extended tool life.

Detailed Features

▸Valveless design reduces maintenance and downtime
▸High-frequency impact for fast penetration
▸Compatible with standard 2-inch drill pipes
▸Durable alloy steel construction
▸Optimized air passages for efficient flushing
▸Lightweight and compact for easy handling
▸Precision-machined internal parts for long life
▸Cost-effective and reliable performance

Packaging & Shipping

Each Kaishan L2 DTH hammer is packed in a wooden case with foam protection, suitable for sea and air transport. Standard export packing ensures safe delivery. We can also customize packaging according to customer requirements. Delivery time is typically 15-30 days after order confirmation, depending on quantity. Shipping ports include Shanghai, Ningbo, or Qingdao, China. For urgent orders, please contact our sales team to discuss expedited options.

After-Sales Service

Kaishan offers a 12-month warranty on the L2 DTH hammer against manufacturing defects. Our dedicated after-sales team provides 24-hour online support and technical assistance. We offer free training for operators and maintenance personnel at our factory or on-site (conditions apply). Genuine spare parts are available worldwide through our distributor network, ensuring quick replacement and minimal downtime. For any service inquiries, please contact our global service hotline or email.
