📦 DTH Drill Bits

Kaishan L2 DTH Drill Bit for Mining & Water Well

Name: Kaishan L2 DTH Drill Bit for Mining & Water Well
Brand: Kaishan
SKU: L2
Availability: InStock

Model: L2

The Kaishan L2 DTH drill bit is a high-performance down-the-hole tool designed for demanding mining, quarrying, and water well drilling operations. As a core component in the Drilling Tools category, this DTH hammer bit delivers reliable penetration in hard rock formations. Engineered with premium carbide buttons and a robust steel body, the L2 model ensures excellent wear resistance and efficient energy transfer from the hammer. It is compatible with standard DTH hammers and is ideal for blast hole drilling, foundation work, and geothermal projects. With a focus on durability and consistent performance, the Kaishan L2 helps reduce downtime and lower cost per meter drilled. Whether you are drilling in granite, limestone, or sandstone, this bit provides the stability and speed your operation requires. Backed by Kaishan's global service network, the L2 is a smart choice for contractors seeking productivity and long service life in tough drilling conditions.

Best For

Mining Blast Hole Drilling Water Well Drilling Quarrying and Aggregate Production Construction and Foundation Work

Technical Specifications

Model	Kaishan L2
Type	DTH Drill Bit
Size	110 mm (standard); other sizes available
Application	Mining, quarrying, water well drilling, construction
Material	Alloy steel body with tungsten carbide buttons
Weight	Approx. 15 kg (for 110 mm size)
Packing	Wooden case or carton, palletized for export

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan L2 DTH drill bit is a premium down-the-hole tool engineered for professionals in mining, quarrying, water well, and construction drilling. As part of Kaishan's extensive Drilling Tools line, the L2 is specifically designed to deliver high penetration rates and exceptional durability in hard and abrasive rock formations. This bit is compatible with most standard DTH hammers, making it a versatile choice for contractors worldwide. ## Technical Features The L2 features a robust steel body manufactured from high-quality alloy steel, heat-treated to withstand extreme impact and fatigue. Its carbide buttons are precision-pressed and graded for optimal wear resistance, ensuring consistent performance over the bit's lifespan. The bit's head design optimizes air flow for efficient cuttings removal, reducing regrinding and improving drilling efficiency. The spline and shank configuration ensures a secure fit with the hammer, minimizing energy loss during operation. Available in various diameters, the L2 can be tailored to specific project requirements. ## Applications The Kaishan L2 is ideal for blast hole drilling in open-pit mines, quarrying, and construction sites. It excels in water well drilling where hard rock layers are encountered. The bit is also suitable for geothermal drilling, foundation piling, and other applications requiring reliable penetration in challenging ground conditions. Its design allows for efficient operation in both vertical and horizontal drilling orientations. ## Performance Benefits Operators choose the L2 for its consistent penetration rates, long service life, and low cost per meter. The bit's optimized button layout and flushing holes reduce the risk of jamming and ensure smooth cuttings evacuation. This translates to less downtime and higher productivity. The L2 is engineered to maintain gauge diameter, reducing the need for reaming and ensuring hole accuracy. ## Quality Assurance Every Kaishan L2 DTH bit undergoes rigorous quality control, from raw material inspection to final performance testing. Kaishan's commitment to excellence ensures that each bit meets international standards for reliability and safety. With a global network of distributors and service centers, Kaishan provides timely support and genuine spare parts to keep your operations running smoothly.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

Approx. 15 kg (for 110 mm size)

Model

Kaishan L2

Type

DTH Drill Bit

Size

110 mm (standard); other sizes available

Application

Mining, quarrying, water well drilling, construction

Material

Alloy steel body with tungsten carbide buttons

Packing

Wooden case or carton, palletized for export

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

High-quality carbide buttons for superior wear resistance

✓

Robust alloy steel body for extended service life

✓

Optimized air flow design for efficient cuttings removal

✓

Compatible with standard DTH hammers

✓

Available in multiple diameters for various applications

✓

Heat-treated for maximum impact toughness

✓

Precision manufacturing ensures consistent performance

✓

Reduces cost per meter drilled

Applications

📍 Mining Blast Hole Drilling

Used in open-pit mines for drilling blast holes in hard rock such as granite and basalt.

Solution: The L2's durable carbide buttons and optimized flushing holes ensure fast penetration and long life, reducing drilling costs.

📍 Water Well Drilling

Ideal for drilling water wells in hard rock formations where standard bits wear quickly.

Solution: With its robust construction and efficient energy transfer, the L2 maintains high penetration rates and hole accuracy.

📍 Quarrying and Aggregate Production

Employed in quarries for drilling blast holes in limestone, sandstone, and other abrasive rocks.

Solution: The L2's wear-resistant design minimizes downtime and ensures consistent performance, maximizing quarry productivity.

📍 Construction and Foundation Work

Suitable for foundation piling, anchoring, and site investigation drilling in urban construction.

Solution: The bit's reliable performance and compatibility with various hammers make it a versatile tool for contractors.

Low Pressure Series Models

Compare specifications across the series to find the right model.

Model	Model	Type	Size	Application	Material	Inquire
L2This model	Kaishan L2	DTH Drill Bit	110 mm (standard); other sizes available	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
L3	Kaishan L3	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, Quarrying, Water Well, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote
L2	Kaishan L2	Low-pressure DTH Hammer	2-inch (compatible with 64-76 mm bits)	Water well drilling, mining, quarrying, construction	Alloy steel with heat treatment	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Carbide buttons
Steel body
Flushing holes
Spline shank
Retainer ring
Bit head
Gauge buttons
Face buttons

Working Principle

The Kaishan L2 DTH drill bit operates on the principle of down-the-hole percussion. Compressed air is fed through the drill string to the DTH hammer, which houses a piston that strikes the bit's shank at high frequency. This impact energy is transferred through the bit body to the carbide buttons, which crush and fracture the rock. Simultaneously, the exhaust air flows through the bit's flushing holes to remove cuttings from the hole bottom, preventing regrinding. The bit rotates slowly, indexing the buttons to new positions for even wear. The combination of impact, rotation, and flushing enables efficient drilling in hard rock. The L2's design optimizes this process by ensuring maximum energy transfer and effective cuttings evacuation, resulting in high penetration rates and extended bit life.

Detailed Features

▸Premium carbide buttons for high wear resistance
▸Heat-treated alloy steel body for toughness
▸Optimized flushing holes for efficient cleaning
▸Compatible with standard DTH hammers
▸Available in various diameters
▸Precision manufacturing for consistent quality
▸Reduces cost per meter drilled
▸Long service life in abrasive rock

Packaging & Shipping

Each Kaishan L2 DTH drill bit is individually packed in a protective wooden case or carton, with anti-rust oil applied to prevent corrosion during transport. Bits are then palletized and shrink-wrapped for container loading. Standard export packaging ensures safe delivery to any major port worldwide. Lead time is typically 15-30 days after order confirmation, depending on quantity. We ship from Shanghai or Ningbo port, with flexible shipping terms (FOB, CIF, etc.) to meet customer requirements.

After-Sales Service

Kaishan offers a comprehensive after-sales service for the L2 DTH drill bit. All products come with a 6-month warranty against manufacturing defects. Our 24-hour technical support team is available to assist with troubleshooting and application advice. We provide training for operators on proper bit usage and maintenance to maximize performance. Genuine spare parts are stocked in regional warehouses for quick delivery. Our global network ensures timely service and support wherever you operate.

Frequently Asked Questions

What is the Kaishan L2 DTH drill bit used for?+

The Kaishan L2 is a down-the-hole drill bit used for mining, quarrying, water well drilling, and construction. It is designed for drilling blast holes, water wells, and foundation holes in hard rock formations.

What sizes are available for the L2 bit?+

The L2 is available in various diameters, typically ranging from 90mm to 200mm, to suit different DTH hammers and application requirements. Custom sizes can be ordered.

What material are the carbide buttons made of?+

The carbide buttons are made of high-quality tungsten carbide with a cobalt binder, selected for optimal hardness and wear resistance in abrasive rock conditions.

Is the L2 compatible with other brands of DTH hammers?+

Yes, the L2 is designed to be compatible with most standard DTH hammers available in the market. Please confirm the shank type and size before ordering.

How long does the L2 drill bit last?+

Bit life depends on rock conditions, drilling parameters, and operator skill. Under normal conditions, the L2 offers excellent service life, often drilling hundreds of meters before requiring resharpening or replacement.

What is the warranty and after-sales support?+

We offer a 6-month warranty against manufacturing defects. Our 24-hour support team provides technical assistance, and we stock genuine spare parts for quick delivery worldwide.
