Kaishan KSC-1300 Water Well Drilling Rig

Name: Kaishan KSC-1300 Water Well Drilling Rig
Brand: Kaishan
SKU: KSC-1300
Availability: InStock

Model: KSC-1300

The Kaishan KSC-1300 water well drilling rig is a truck-mounted DTH and mud rotary drilling rig engineered for deep water wells, geothermal boreholes, and mineral exploration. With a rated drilling depth of 1300 m and a hole diameter range of 105–350 mm, it combines a powerful diesel engine, high-torque rotary head, and heavy-duty mast to deliver reliable performance in hard rock and unconsolidated formations. The KSC-1300 supports DTH hammer, mud rotary, and air rotary drilling methods, making it a versatile solution for water supply projects, irrigation wells, and construction dewatering. Its hydraulic top-drive system, integrated air compressor interface, and advanced control panel ensure efficient penetration rates, low operating costs, and safe operation. Designed for global markets, this rig meets emission and safety standards, and is backed by Kaishan's worldwide service network. Whether drilling in remote mountainous areas or urban job sites, the KSC-1300 offers the power, mobility, and durability required for demanding water well drilling operations.

Best For

Water Well Drilling Geothermal Boreholes Mineral Exploration Construction Dewatering

Technical Specifications

Model	KSC-1300
Drilling Depth	1300 m
Hole Diameter	105–350 mm
Drilling Method	DTH Hammer / Mud Rotary / Air Rotary
Engine Power	336 kW (Cummins)
Weight	28,000 kg
Dimension (L×W×H)	12,000 × 2,500 × 4,000 mm

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan KSC-1300 is a heavy-duty water well drilling rig designed for deep boreholes up to 1300 meters. It integrates a robust truck chassis, a high-torque hydraulic rotary head, and a telescopic mast to deliver exceptional drilling efficiency in diverse geological conditions. This rig is ideal for water well contractors, geothermal installers, and mining exploration companies seeking a reliable, mobile drilling solution. ## Technical Features The KSC-1300 features a powerful Cummins diesel engine rated at 336 kW, providing ample power for DTH hammer drilling and mud rotary operations. The hydraulic top-drive offers infinitely variable speeds and high torque, ensuring optimal penetration rates in hard rock. A heavy-duty feed system with 12,000 kgf pull-up force and 6,000 kgf feed force enhances drilling control. The rig is equipped with a four-stage air filter, hydraulic oil cooler, and centralized lubrication system for extended service intervals. The operator's cabin is ergonomically designed with joystick controls and digital displays for real-time monitoring of drilling parameters. ## Applications This rig excels in water well drilling, geothermal borehole construction, and mineral exploration. Its ability to switch between DTH, mud rotary, and air rotary methods makes it suitable for both consolidated and unconsolidated formations. The KSC-1300 is also used for construction dewatering, slope stabilization, and micro-piling. With a compact footprint and excellent mobility, it can be deployed in remote areas, mountainous terrain, and urban job sites. ## Why Choose Kaishan KSC-1300 Kaishan is a global leader in drilling equipment, and the KSC-1300 reflects decades of engineering expertise. It offers unmatched reliability, low operating costs, and superior after-sales support. The rig is CE certified and complies with international emission standards. Its modular design simplifies maintenance and reduces downtime. Whether you are drilling a 1300-meter water well or a shallow geothermal loop, the KSC-1300 delivers consistent performance and high productivity.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Hole Diameter

105–350 mm

Drilling Depth

1300 m

Engine Power

336 kW (Cummins)

Weight

28,000 kg

Dimension (L×W×H)

12,000 × 2,500 × 4,000 mm

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Rated drilling depth of 1300 m for deep water wells

✓

Hole diameter range 105–350 mm for versatile applications

✓

Powerful 336 kW Cummins diesel engine for hard rock drilling

✓

Hydraulic top-drive with high torque and variable speed

✓

Supports DTH hammer, mud rotary, and air rotary methods

✓

Truck-mounted design for excellent mobility and quick setup

Applications

📍 Water Well Drilling

Drilling deep water wells for municipal, agricultural, and industrial water supply.

Solution: KSC-1300's 1300 m depth capacity and DTH hammer capability ensure fast penetration in hard rock aquifers.

📍 Geothermal Boreholes

Installation of geothermal heat exchange loops for heating and cooling systems.

Solution: Precise hole diameter control and mud rotary method prevent formation damage and ensure efficient loop installation.

📍 Mineral Exploration

Core drilling and sampling for mineral resource evaluation.

Solution: The rig's high torque and stable feed system allow for accurate core recovery and reliable sample collection.

📍 Construction Dewatering

Drilling dewatering wells for construction sites and mines.

Solution: Rapid setup and high drilling speed reduce project timelines; the rig can handle large-diameter holes for high-flow pumps.

TEC Series Models

Compare specifications across the series to find the right model.

☑	Model	Model	Drilling Depth	Hole Diameter	Drilling Method	Engine Power	Inquire
	KSC-1300This model	KSC-1300	1300 m	105–350 mm	DTH Hammer / Mud Rotary / Air Rotary	336 kW (Cummins)	Get a Quote
	CZT-1200	CZT-1200	1200 m	140-350 mm	DTH / Mud Rotary / Rotary	194 kW	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Truck chassis
Diesel engine
Hydraulic rotary head
Telescopic mast
Feed system
Operator cabin
Control panel
Drill string and bit

Working Principle

The Kaishan KSC-1300 operates on a top-drive rotary drilling principle. A powerful diesel engine drives hydraulic pumps that supply pressurized oil to the rotary head, which rotates the drill string. The drill string transmits torque and weight-on-bit to the drill bit, which breaks rock through rotation and impact. For DTH hammer drilling, compressed air is directed through the drill pipe to actuate the hammer, while the returning air lifts cuttings to the surface. In mud rotary mode, drilling fluid is pumped down the drill pipe to cool the bit and carry cuttings up the annulus. The rig's feed system applies controlled pull-down force to maintain optimal bit load. The operator monitors torque, rotation speed, air pressure, and penetration rate from the control panel, adjusting parameters for maximum efficiency. The mast supports the drill string and allows for efficient pipe handling, while the truck-mounted chassis enables rapid relocation between boreholes.

Detailed Features

▸Deep drilling capacity up to 1300 m
▸Versatile drilling methods: DTH, mud rotary, air rotary
▸High-torque hydraulic top-drive
▸Powerful 336 kW Cummins engine
▸Truck-mounted for mobility
▸Ergonomic operator cabin with joystick controls
▸Centralized lubrication and easy maintenance
▸CE certified and emission compliant

Packaging & Shipping

The Kaishan KSC-1300 is shipped as a complete truck-mounted unit, partially disassembled for transport efficiency. The mast and drill pipes are packed in sturdy wooden crates, while the truck chassis is secured on a flat rack or in a 40-foot container. Shipping dimensions and weight are optimized for standard ocean freight. Delivery time is typically 30–45 days after order confirmation, depending on configuration. Ports of departure include Shanghai, Qingdao, or Tianjin, China. All shipments include detailed packing lists, certificates of origin, and compliance documents.

After-Sales Service

Kaishan provides comprehensive after-sales service for the KSC-1300, including a 12-month warranty on major components (excluding wear parts). A 24-hour technical support hotline is available for troubleshooting and spare parts ordering. We offer on-site installation and commissioning services, as well as operator training programs at our factory or at the customer's site. A global network of authorized service centers ensures quick access to genuine spare parts and expert assistance. Preventive maintenance kits and extended warranty options are also available.

Frequently Asked Questions

What is the drilling depth and hole diameter of the KSC-1300?+

The KSC-1300 has a rated drilling depth of 1300 m and a hole diameter range of 105–350 mm. It supports DTH hammer, mud rotary, and air rotary drilling methods. This range covers deep water wells, geothermal boreholes, and mineral exploration.

What engine powers the KSC-1300 water well drilling rig?+

The KSC-1300 uses a 336 kW Cummins diesel engine. This power supports DTH hammer drilling and mud rotary operations in hard rock. The rig weighs 28,000 kg and measures 12,000 × 2,500 × 4,000 mm.

What air supply does the KSC-1300 need for DTH hammer drilling?+

The KSC-1300 supports DTH hammer, mud rotary, and air rotary methods with a hole diameter range of 105–350 mm. It has an integrated air compressor interface for the required air supply. Match the DTH hammer and button bit to the 105–350 mm hole diameter.

What applications suit the KSC-1300 truck-mounted rig?+

The KSC-1300 suits water well drilling, geothermal boreholes, mineral exploration, and construction dewatering. Its 1300 m depth and 105–350 mm hole diameter cover deep boreholes. The truck-mounted design provides mobility and quick setup on site.

How is the KSC-1300 shipped and what is the delivery time?+

The KSC-1300 ships as a complete truck-mounted unit, partially disassembled for transport efficiency. The mast and drill pipes are packed in wooden crates, and the truck chassis is secured on a flat rack or in a 40-foot container. Delivery time is typically 30–45 days after order confirmation.

What warranty and after-sales service come with the KSC-1300?+

The KSC-1300 includes a 12-month warranty on major components, excluding wear parts. A 24-hour technical support hotline is available for troubleshooting and spare parts ordering. On-site installation, commissioning, and operator training are also offered.

Which drilling methods does the KSC-1300 support?+

The KSC-1300 supports DTH hammer, mud rotary, and air rotary drilling methods. It reaches a rated depth of 1300 m with a hole diameter of 105–350 mm. This makes it suitable for hard rock and unconsolidated formations.

What are the dimensions and weight of the KSC-1300?+

The KSC-1300 measures 12,000 × 2,500 × 4,000 mm and weighs 28,000 kg. It is a truck-mounted rig with a 336 kW Cummins engine. The rated drilling depth is 1300 m with a hole diameter of 105–350 mm.
