Kaishan KS300 Portable Diesel Air Compressor
Model: KS300
The Kaishan KS300 portable diesel air compressor delivers reliable high-pressure compressed air for drilling, mining, and construction. With a free air delivery of 300 CFM and a working pressure of 100 PSI, it is engineered to power DTH hammers, water well rigs, and pneumatic tools in remote job sites. Its heavy-duty diesel engine ensures fuel efficiency and long runtime, while the rugged enclosure protects components from dust and harsh weather. The KS300 features a high-efficiency air end, advanced cooling system, and intuitive control panel for easy operation and maintenance. Whether you are drilling blast holes, operating rock drills, or running sandblasting equipment, this compressor provides consistent airflow and dependable performance. Compact and towable, it integrates seamlessly with Kaishan drilling rigs and other pneumatic systems. Backed by Kaishan's global service network, the KS300 is the ideal choice for contractors seeking a durable, cost-effective compressed air solution.
Technical Specifications
| Model | KS300 |
| Drilling depth(m) | 300M |
| The hole diameter(mm) | 140-325 |
| The weight（T） | 7.5 |
| Drill pipe diamete(mm) | φ76 φ89 φ102 |
| Drill pipe length(m) | 1.5m 2.0m 3.0m |
| Dimension (L×W×H) | 4100*2000*2500MM |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
The hole diameter(mm)
140-325
Drilling depth(m)
300M
Drill pipe diamete(mm)
φ76 φ89 φ102
The weight（T）
7.5
Dimension (L×W×H)
4100*2000*2500MM
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
300 CFM free air delivery at 100 PSI for demanding pneumatic tools
Fuel-efficient diesel engine with large fuel tank for extended runtime
High-efficiency rotary screw air end for continuous duty operation
Rugged, weather-resistant enclosure protects against dust and debris
Advanced cooling system ensures stable performance in high temperatures
Multiple air outlet ports for simultaneous tool operation
Easy-to-use control panel with safety shutdowns and gauges
Towable chassis for easy transport between job sites
Applications
📍 Mining and Quarrying
Powers DTH hammers, rock drills, and pneumatic loaders in open-pit and underground mines.
Solution: The KS300 provides consistent 300 CFM air to operate multiple drills, increasing productivity in blast hole drilling.
📍 Water Well Drilling
Supports water well drilling rigs requiring high-pressure air for hammer operation and cuttings removal.
Solution: Its 100 PSI working pressure and 300 CFM output efficiently drive DTH hammers for deep water wells.
📍 Construction and Sandblasting
Ideal for sandblasting, concrete breaking, and pneumatic tool operation on construction sites.
Solution: The KS300 delivers reliable air for sandblasting equipment and multiple pneumatic tools simultaneously.
📍 Oil and Gas Exploration
Used in seismic drilling and exploration activities requiring portable, high-volume compressed air.
Solution: Compact and towable, the KS300 can be easily moved across rough terrain to power exploration drills.
Similar Models in This Category
This model is unique in its series — here are similar models from the same category.
| ☑ | Model | Model | Drill pipe diamete(mm) | Drill pipe length(m) | Dimension (L×W×H) | Drilling Depth | Inquire |
|---|---|---|---|---|---|---|---|
| KS300This model | KS300 | φ76 φ89 φ102 | 1.5m 2.0m 3.0m | 4100*2000*2500MM | — | Get a Quote | |
| KW360 | KW360 | — | — | 8,500 × 2,300 × 3,200 mm | 360 m | Get a Quote | |
| KW180 | KW180 | φ76 φ89 | 1.5m 2.0m 3.0m | 3950 × 1630 × 2250 mm | 180 m | Get a Quote | |
| KS260 | KS260 | — | — | 3900 × 7500 × 2250 mm | 260 m | Get a Quote | |
| KS350 | Kaishan KS350 | φ89 φ102 | 1.5m 2.0m 3.0m | 6000 × 2,000 × 2,550 mm | 350 m | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Diesel engine
- Rotary screw air end
- Air filter
- Oil separator
- Cooling system
- Control panel
- Fuel tank
- Towable chassis
Working Principle
The Kaishan KS300 operates on the principle of rotary screw compression. A diesel engine drives the male and female rotors inside the air end. As the rotors mesh, air is trapped in the spaces between them and progressively compressed as the rotors turn. The compressed air then passes through a separator to remove oil, a cooler to reduce temperature, and finally to the outlet ports. The engine speed is regulated to match air demand, ensuring efficient fuel use. An advanced control system monitors pressure, temperature, and oil level, automatically shutting down the unit if any parameter exceeds safe limits. This continuous process delivers a steady flow of compressed air for demanding applications.
Detailed Features
- ▸High-efficiency rotary screw air end
- ▸Fuel-efficient diesel engine
- ▸Weather-resistant enclosure
- ▸Advanced cooling system
- ▸Multiple air outlet ports
- ▸Easy-to-read control panel
- ▸Safety shutdown system
- ▸Towable and compact design
Packaging & Shipping
The Kaishan KS300 is shipped in a protective wooden crate or steel frame, depending on order size. For LCL shipments, it is securely packed to prevent movement. For FCL, units can be loaded into 20ft or 40ft containers. Typically, one 20ft container can hold 2 units. Delivery time is 15-30 days after deposit, depending on quantity. Ports of shipment include Shanghai or Ningbo, China. Custom packaging and labeling are available upon request.
After-Sales Service
Kaishan offers a 12-month warranty on the KS300 compressor, covering manufacturing defects. A 24-hour technical support hotline is available for troubleshooting. We provide free online training for operators and maintenance personnel. Spare parts are available through our global distribution network, ensuring quick delivery. On-site service can be arranged for large orders. Our dedicated after-sales team ensures minimal downtime and maximum productivity.
Frequently Asked Questions
What is the air output of the Kaishan KS300 compressor?+
The KS300 delivers a free air delivery of 300 CFM at a working pressure of 100 PSI. This output supports DTH hammers, water well rigs and pneumatic tools. It is built for continuous duty operation on demanding job sites.
What engine powers the KS300 portable diesel air compressor?+
The KS300 is powered by a fuel-efficient diesel engine matched to the rotary screw air end. The engine and large fuel tank support extended runtime on remote sites. The diesel drive makes the unit suitable for locations without grid power.
What equipment can the KS300 compressor run?+
The KS300 supplies 300 CFM at 100 PSI to power DTH hammers, water well rigs and pneumatic tools. It integrates with Kaishan drilling rigs and other pneumatic systems. Multiple air outlet ports allow simultaneous tool operation.
What applications is the KS300 diesel compressor suitable for?+
The KS300 is used in mining and quarrying, water well drilling, construction and sandblasting, and oil and gas exploration. Its weather-resistant enclosure protects components from dust and debris. The towable chassis allows transport between remote job sites.
How is the Kaishan KS300 compressor packaged and shipped?+
The KS300 is shipped in a protective wooden crate or steel frame, depending on order size. For FCL shipments, one 20ft container can hold 2 units, and units can also be loaded into 40ft containers. Ports of shipment include Shanghai or Ningbo, China.
What warranty and support come with the KS300 compressor?+
Kaishan offers a 12-month warranty on the KS300 compressor covering manufacturing defects. A 24-hour technical support hotline is available for troubleshooting, along with free online training for operators and maintenance personnel. Spare parts are available through the global distribution network.
What is the delivery time for the KS300 air compressor?+
Delivery time for the KS300 is 15-30 days after deposit, depending on quantity. Units ship from Shanghai or Ningbo, China. For LCL shipments, the compressor is securely packed to prevent movement.
