Kaishan KS313 Hydraulic Mining Drilling Rig

Name: Kaishan KS313 Hydraulic Mining Drilling Rig
Brand: Kaishan
SKU: KS313
Availability: InStock

Model: KS313

Kaishan KS313 Hydraulic Mining Drilling Rig (official model KS313). Source: Zhejiang Kaishan Heavy Industry product centre. ｜官方中文名：KS313型矿用液压采矿钻车

Best For

Underground Metal Mining Tunnel Construction Roof Bolting Underground Cavern Excavation

Technical Specifications

Model	Kaishan KS313
Drilling Depth	30 m
Hole Diameter	45–76 mm
Drilling Method	Top hammer hydraulic drilling
Engine Power	60 kW
Weight	7,500 kg
Dimension (L×W×H)	6,000 × 1,800 × 2,200 mm

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

The Kaishan KS313 is a compact underground mining drilling rig engineered for efficient blast hole drilling in narrow vein and tunnel development. Designed for underground mining drilling rig applications, it combines a robust boom system, high-frequency rock drill, and reliable diesel engine to deliver consistent performance in confined spaces. With a drilling depth of up to 30 meters and hole diameter range of 45–76 mm, the KS313 excels in hard rock conditions using top hammer drilling. Its articulated chassis and four-wheel drive ensure stable maneuverability on rough underground roads. The rig features an ergonomic control panel, efficient dust suppression system, and easy maintenance access, reducing downtime and improving safety. Ideal for small to medium-scale mining operations, the KS313 offers a cost-effective solution for face drilling, roof bolting, and auxiliary drilling tasks. Backed by Kaishan's global service network, this underground drilling rig ensures high productivity and low operating costs in demanding underground environments.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Hole Diameter

45–76 mm

Drilling Depth

30 m

Engine Power

60 kW

Weight

7,500 kg

Dimension (L×W×H)

6,000 × 1,800 × 2,200 mm

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Compact design for narrow underground workings

✓

High-frequency hydraulic rock drill for fast penetration

✓

Articulated chassis with four-wheel drive for superior maneuverability

✓

Drilling depth up to 30 m and hole diameter 45–76 mm

✓

Ergonomic control panel and automatic rod handling

✓

Efficient dust suppression system for safer operation

✓

Reliable diesel engine with low emissions

✓

Easy maintenance access to reduce downtime

Applications

📍 Underground Metal Mining

Face drilling and blast hole drilling in narrow vein metal mines.

Solution: KS313's compact size and powerful rock drill enable efficient drilling in confined stopes, improving ore extraction productivity.

📍 Tunnel Construction

Drilling blast holes for tunnel excavation in railway, highway, and water diversion projects.

Solution: The rig's articulated boom and high penetration rate ensure fast face drilling, accelerating tunnel advance cycles.

📍 Roof Bolting

Installing rock bolts for ground support in underground mines and tunnels.

Solution: KS313 can be equipped with a bolting system for quick and secure roof bolting, enhancing worker safety.

📍 Underground Cavern Excavation

Drilling for underground storage caverns, hydropower stations, and military facilities.

Solution: With its versatile boom and reliable power, the KS313 handles varied drilling patterns in large caverns efficiently.

Similar Models in This Category

This model is unique in its series — here are similar models from the same category.

Model	Model	Drilling Depth	Hole Diameter	Drilling Method	Engine Power	Inquire
KS313This model	Kaishan KS313	30 m	45–76 mm	Top hammer hydraulic drilling	60 kW	Get a Quote
KQLG-115	KQLG-115	25 m	90–152 mm	DTH and Rotary	78 kW	Get a Quote
KAISHAN KJ310	Kaishan KJ310	—	32-76 mm	Rotary / DTH	45 kW	Get a Quote
KAISHAN KJ311	Kaishan KJ311	—	32-76mm	Hydraulic percussion + rotation	93 kW	Get a Quote
KAISHAN KJ311D	Kaishan KJ311	—	32–89 mm	Top Hammer / DTH	45 kW	Get a Quote
KJ422	Kaishan KJ422	—	76-152 mm	DTH / Rotary	—	Get a Quote
KJ421	Kaishan KJ421	—	—	Hydraulic percussion	93 kW	Get a Quote
KM211	Kaishan KM211	—	—	Top Hammer / DTH	60 kW	Get a Quote
KM311	Kaishan KM311	—	—	DTH / Rotary	60 kW	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Hydraulic rock drill
Boom and feed beam
Articulated chassis
Diesel engine
Control panel
Dust suppression system
Drill string (rods and bits)
Four-wheel drive system

Working Principle

The Kaishan KS313 underground mining drilling rig operates on a top hammer drilling principle. A high-frequency hydraulic rock drill delivers impact energy, rotation, and feed force to the drill string. The piston in the rock drill strikes the shank adapter, generating a stress wave that travels through the drill rods to the bit. The bit crushes the rock at the bottom of the hole, while rotation indexes the bit for new positions. Flushing water or air removes cuttings from the hole. The rig's hydraulic system powers the boom, feed beam, and rock drill, allowing precise positioning and controlled drilling. The operator controls all functions from an ergonomic panel, ensuring efficient and safe operation. The articulated chassis and four-wheel drive enable maneuverability in underground tunnels, while the diesel engine provides reliable power for both tramming and drilling. This system ensures high penetration rates and accurate hole placement in hard rock conditions.

Detailed Features

▸Compact and robust design for underground environments
▸High-frequency hydraulic rock drill for fast drilling
▸Articulated boom for wide coverage and precise positioning
▸Four-wheel drive for excellent traction and maneuverability
▸Ergonomic control panel for operator comfort
▸Automatic rod handling for efficiency and safety
▸Efficient dust suppression system
▸Easy access for maintenance and service

Packaging & Shipping

The Kaishan KS313 is shipped in a disassembled state for efficient container loading. Main components are secured on steel pallets and protected with anti-rust coating and waterproof wrapping. Standard export packaging ensures safe transport by sea. The rig can be loaded into a 40HQ container. Delivery time is approximately 30–45 days after order confirmation, depending on configuration. Port of shipment: Shanghai or Ningbo, China. Customized packaging and shipping arrangements are available upon request.

After-Sales Service

Kaishan provides comprehensive after-sales service for the KS313. All new rigs come with a 12-month warranty or 2000 working hours, whichever comes first, covering major components. A 24-hour technical support hotline is available for troubleshooting. We offer on-site installation and commissioning, operator training, and maintenance guidance. Genuine spare parts are stocked in regional warehouses for quick delivery. Our global service network ensures prompt response and minimal downtime. Regular maintenance kits and extended warranty options are also available.

Frequently Asked Questions

What hole diameter and drilling depth does the Kaishan KS313 cover?+

The KS313 drills holes of 45–76 mm in diameter to a maximum drilling depth of 30 m. It uses top hammer hydraulic drilling for blast hole work in underground mining.

What engine power does the Kaishan KS313 use?+

The KS313 is powered by a 60 kW diesel engine. The rig weighs 7,500 kg and measures 6,000 × 1,800 × 2,200 mm.

What drilling method does the KS313 use?+

The KS313 uses top hammer hydraulic drilling with a high-frequency hydraulic rock drill. It is built for hard rock conditions in confined underground workings.

Where can the Kaishan KS313 be used?+

The KS313 suits underground metal mining, tunnel construction, roof bolting and underground cavern excavation. Its compact design and articulated chassis with four-wheel drive handle narrow workings and rough underground roads.

How is the Kaishan KS313 shipped?+

The KS313 is shipped disassembled for container loading, with main components secured on steel pallets and protected by anti-rust coating and waterproof wrapping. It can be loaded into a 40HQ container, with delivery approximately 30–45 days after order confirmation.

What warranty and support come with the KS313?+

New KS313 rigs carry a 12-month warranty or 2000 working hours, whichever comes first, covering major components. A 24-hour technical support hotline, on-site installation and commissioning, operator training and maintenance guidance are provided.

What maintenance features does the Kaishan KS313 offer?+

The KS313 has easy maintenance access to reduce downtime. It also includes an ergonomic control panel, automatic rod handling and an efficient dust suppression system.
