Kaishan KJ215 Hydraulic Tunnelling Drilling Rig
Model: KJ215
Kaishan KJ215 Hydraulic Tunnelling Drilling Rig (official model KJ215). Source: Zhejiang Kaishan Heavy Industry product centre. ｜ 官方中文名：KJ215型矿用液压掘进钻车（窄巷道型）
Best For
Technical Specifications
| Model | Kaishan KJ215 |
| Drilling Depth | 30 m |
| Hole Diameter | 45–102 mm |
| Drilling Method | Top hammer hydraulic drilling |
| Engine Power | 74 kW |
| Weight | 12,000 kg |
| Dimension (L×W×H) | 9,000 × 2,200 × 2,600 mm |
Product Details
Technical Selection
Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.
Hole Diameter
45–102 mm
Drilling Depth
30 m
Engine Power
74 kW
Weight
12,000 kg
Dimension (L×W×H)
9,000 × 2,200 × 2,600 mm
Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.
Check with an engineerKey Advantages
Compact articulated chassis for narrow-vein and tunnel access
Single hydraulic boom with 30 m drilling depth and 45–102 mm hole diameter
Top hammer drilling with high-frequency hydraulic rock drill
74 kW diesel engine with optional electric power for reduced emissions
Four-wheel drive and articulated steering for excellent maneuverability
Ergonomic operator station with joystick controls and good visibility
Applications
📍 Underground Mine Development
Face drilling and production drilling in tunnels and ore drives.
Solution: The KJ215 provides efficient drilling of blast holes with precise positioning, speeding up development cycles.
📍 Roof Bolting and Ground Support
Installation of rock bolts, cable bolts, and mesh for ground control.
Solution: With its adjustable boom and drilling depth, the rig quickly drills bolt holes at various angles, improving safety and productivity.
📍 Narrow-Vein Mining
Drilling in confined stopes and narrow ore bodies.
Solution: The compact design and articulated steering allow the KJ215 to operate in spaces where larger rigs cannot reach, reducing dilution and improving ore recovery.
📍 Auxiliary Drilling
Grouting, drainage, and geological investigation holes.
Solution: The rig’s versatile drilling parameters and optional accessories enable efficient auxiliary drilling for various underground tasks.
Similar Models in This Category
This model is unique in its series — here are similar models from the same category.
| ☑ | Model | Model | Drilling Depth | Hole Diameter | Drilling Method | Engine Power | Inquire |
|---|---|---|---|---|---|---|---|
| KJ215This model | Kaishan KJ215 | 30 m | 45–102 mm | Top hammer hydraulic drilling | 74 kW | Get a Quote | |
| KQLG-115 | KQLG-115 | 25 m | 90–152 mm | DTH and Rotary | 78 kW | Get a Quote | |
| KAISHAN KJ310 | Kaishan KJ310 | — | 32-76 mm | Rotary / DTH | 45 kW | Get a Quote | |
| KAISHAN KJ311 | Kaishan KJ311 | — | 32-76mm | Hydraulic percussion + rotation | 93 kW | Get a Quote | |
| KAISHAN KJ311D | Kaishan KJ311 | — | 32–89 mm | Top Hammer / DTH | 45 kW | Get a Quote | |
| KJ422 | Kaishan KJ422 | — | 76-152 mm | DTH / Rotary | — | Get a Quote | |
| KJ421 | Kaishan KJ421 | — | — | Hydraulic percussion | 93 kW | Get a Quote | |
| KM211 | Kaishan KM211 | — | — | Top Hammer / DTH | 60 kW | Get a Quote | |
| KM311 | Kaishan KM311 | — | — | DTH / Rotary | 60 kW | Get a Quote |
Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.
Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.
Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.
Main Components
- Hydraulic boom
- Hydraulic rock drill
- Feed beam
- Control panel
- Diesel engine
- Articulated chassis
- Four-wheel drive system
- Operator cabin
Working Principle
The Kaishan KJ215 underground mining drilling rig operates on a top hammer hydraulic drilling principle. A diesel engine powers the hydraulic system, which drives the boom, feed, and rock drill. The hydraulic rock drill delivers high-frequency impact energy to the drill string, while the rotation unit turns the bit. Compressed air, supplied by an onboard or external compressor, flushes cuttings from the hole. The feed beam advances the drill string into the rock, and the boom positions the drill accurately. The operator controls all functions via joysticks from an ergonomic cabin, ensuring precise and efficient drilling. The rig’s articulated chassis and four-wheel drive enable tramming on rough underground roads.
Detailed Features
- ▸Compact design for narrow underground workings
- ▸Powerful hydraulic rock drill for hard rock
- ▸Maximum drilling depth of 30 meters
- ▸Hole diameter range of 45–102 mm
- ▸74 kW diesel engine with optional electric drive
- ▸Four-wheel drive and articulated steering
- ▸Ergonomic operator station with joystick controls
- ▸Global service and spare parts support
Packaging & Shipping
The Kaishan KJ215 is shipped in a 40HQ container with proper blocking and waterproof wrapping. Delivery time is 30–45 days after order confirmation. Port of shipment: Shanghai or Ningbo, China.
After-Sales Service
Kaishan offers a 12-month warranty on major components, 24-hour online technical support, on-site training for operators and maintenance staff, and a global spare parts network to ensure quick availability.
Frequently Asked Questions
What hole diameter and drilling depth does the Kaishan KJ215 cover?+
The Kaishan KJ215 drills hole diameters from 45 to 102 mm and reaches a drilling depth of up to 30 m. It uses top hammer hydraulic drilling for both production and support holes.
What engine powers the Kaishan KJ215?+
The Kaishan KJ215 is powered by a 74 kW diesel engine. It can also be configured with optional electric power for reduced ventilation demand.
What are the dimensions and weight of the Kaishan KJ215?+
The Kaishan KJ215 measures 9,000 × 2,200 × 2,600 mm (L×W×H) and weighs 12,000 kg. Its compact articulated chassis is built for narrow-vein and tunnel access.
Where can the Kaishan KJ215 be used?+
The Kaishan KJ215 suits underground mine development, roof bolting and ground support, narrow-vein mining and auxiliary drilling. Four-wheel drive and articulated steering allow stable tramming on rough underground roads.
How is the Kaishan KJ215 shipped?+
The Kaishan KJ215 is shipped in a 40HQ container with proper blocking and waterproof wrapping. Delivery time is 30–45 days after order confirmation, with shipment from Shanghai or Ningbo, China.
What after-sales service is offered with the Kaishan KJ215?+
Kaishan offers a 12-month warranty on major components for the KJ215. Support includes 24-hour online technical support, on-site training for operators and maintenance staff, and a global spare parts network.
What drilling method does the Kaishan KJ215 use?+
The Kaishan KJ215 uses top hammer hydraulic drilling with a high-frequency hydraulic rock drill. This method supports hole diameters of 45–102 mm to a depth of 30 m.
