Kaishan SHANK-ADAPTERS DTH Drill Rod Adapter for DTH Hammers

Name: Kaishan SHANK-ADAPTERS DTH Drill Rod Adapter for DTH Hammers
Brand: Kaishan
SKU: SHANK-ADAPTERS
Availability: InStock

Model: SHANK-ADAPTERS

Kaishan SHANK-ADAPTERS are precision-engineered DTH drill rod adapters designed to connect DTH hammers to drill rods in mining, water well, and quarry drilling operations. Manufactured from high-strength alloy steel with heat-treated threads and shanks, these adapters ensure reliable torque transmission and impact energy transfer under extreme down-the-hole conditions. Available in common shank types such as DHD, COP, Mission, and SD series, they fit Kaishan and other major DTH hammers. Each adapter undergoes strict dimensional inspection and thread gauging to guarantee compatibility and long service life. Ideal for blast hole drilling, geothermal wells, and foundation work, Kaishan SHANK-ADAPTERS reduce downtime and improve drilling efficiency. With global shipping, OEM support, and responsive after-sales service, Kaishan provides a complete drilling tools solution for contractors and distributors worldwide.

Best For

Mining Blast Hole Drilling Water Well Drilling Quarry and Aggregate Production Construction Foundation Drilling

Technical Specifications

Model	SHANK-ADAPTERS
Type	DTH Drill Rod Adapter
Size	2"-8" (51mm-203mm) or as per hammer shank
Application	Mining, water well, quarry, construction DTH drilling
Material	High-strength alloy steel, heat-treated
Weight	5-50 kg depending on size
Packing	Wooden case or pallet, anti-rust protection

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

Kaishan SHANK-ADAPTERS are the shank adapter series in the DTH drill rods line, the link between a down-the-hole hammer and the drill rod. The shank end seats in the hammer chuck while the threaded end joins the rod, and a central hole passes flushing air. Machined from heat-treated alloy steel, they suit mining, water well, quarry and foundation duty, and pair with DHD, COP, Mission, SD and QL hammers. Support covers warranty, spare parts and training.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

5-50 kg depending on size

Model

SHANK-ADAPTERS

Type

DTH Drill Rod Adapter

Size

2"-8" (51mm-203mm) or as per hammer shank

Application

Mining, water well, quarry, construction DTH drilling

Material

High-strength alloy steel, heat-treated

Packing

Wooden case or pallet, anti-rust protection

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

Precision-machined from high-strength alloy steel for durability

✓

Heat-treated threads and shank for wear resistance

✓

Compatible with DHD, COP, Mission, SD, QL and other DTH hammers

✓

Strict dimensional inspection ensures perfect fit and torque transfer

✓

Available in multiple sizes to suit various drill rod diameters

✓

Reduces downtime and improves drilling efficiency

Applications

📍 Mining Blast Hole Drilling

Used in open-pit and underground mines to connect DTH hammers to drill rods for efficient blast hole drilling.

Solution: Kaishan SHANK-ADAPTERS provide reliable torque and impact transmission, reducing tool wear and increasing penetration rates.

📍 Water Well Drilling

Essential for water well projects where DTH drilling is required to penetrate hard rock formations.

Solution: Our adapters ensure a secure connection between hammer and rod, minimizing air leakage and improving flushing efficiency.

📍 Quarry and Aggregate Production

Used in quarries for drilling blast holes in limestone, granite, and other hard rocks.

Solution: The robust construction of Kaishan adapters withstands high impact and rotation, extending service life in demanding quarry conditions.

📍 Construction Foundation Drilling

Applied in foundation piling and anchoring where DTH drilling is needed for rock sockets.

Solution: Precision threads and shanks ensure quick and safe coupling, reducing setup time and improving project efficiency.

Accessories Series Models

Compare specifications across the series to find the right model.

☑	Model	Model	Type	Size	Application	Material	Inquire
	SHANK-ADAPTERSThis model	SHANK-ADAPTERS	DTH Drill Rod Adapter	2"-8" (51mm-203mm) or as per hammer shank	Mining, water well, quarry, construction DTH drilling	High-strength alloy steel, heat-treated	Get a Quote
	COUPLING-SLEEVES	COUPLING-SLEEVES	DTH Drill Rod Coupling Sleeve	2 3/8" - 4 1/2" (60mm - 114mm) outer diameter, various thread types	Connecting DTH drill rods in mining, water well, quarry, construction	High-strength alloy steel, heat-treated	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Shank end (hammer connection)
Threaded end (rod connection)
Central flushing hole
Heat-treated alloy steel body
Precision-cut threads
Wear-resistant surface
Chamfered edges
Identification markings

Working Principle

In DTH drilling, the hammer is located at the bottom of the drill string, directly impacting the bit. The SHANK-ADAPTERS serves as the mechanical link between the DTH hammer and the drill rod. It transmits both rotational torque from the drill rig and impact energy from the hammer to the bit, while also allowing flushing air to pass through to clear cuttings. The adapter's shank end fits into the hammer's chuck, and its threaded end connects to the drill rod. When the rig rotates and feeds the string, the adapter ensures that the hammer and rod move as a single unit. The design must withstand high torsional and impact loads, as well as abrasive wear from rock cuttings. Proper heat treatment and precise machining are critical to prevent premature failure. Kaishan SHANK-ADAPTERS are engineered to meet these demands, providing a reliable and efficient connection that enhances overall drilling performance.

Detailed Features

▸High-strength alloy steel construction
▸Precision heat treatment for optimal hardness and toughness
▸Interchangeable with major DTH hammer brands
▸Leak-free thread connection
▸Corrosion-resistant surface finish
▸Available in various sizes and shank types
▸Strict quality control and testing
▸Cost-effective and long-lasting

Packaging & Shipping

Kaishan SHANK-ADAPTERS are packed in wooden cases or pallets, with each adapter protected by anti-rust oil and wrapped in plastic film. Customized packaging is available upon request. For standard orders, lead time is 15-30 days after deposit. Shipping can be arranged via sea, air, or express. Ports of departure include Ningbo, Shanghai, or as per customer requirements. We ensure safe and timely delivery worldwide.

After-Sales Service

Kaishan provides a 12-month warranty on SHANK-ADAPTERS against manufacturing defects. Our dedicated after-sales team offers 24-hour online support and technical assistance. We provide free training materials and can arrange on-site training for bulk orders. A full range of spare parts is available for immediate shipment. Customers can rely on our global service network for prompt solutions.
