Kaishan K80 DTH Drill Bit for Mining & Water Well

Name: Kaishan K80 DTH Drill Bit for Mining & Water Well
Brand: Kaishan
SKU: K80
Availability: InStock

Model: K80

The Kaishan K80 DTH drill bit is a high-performance down-the-hole button bit designed for demanding mining, quarrying, and water well drilling. As a core product in the Drilling Tools category, this DTH Drill Bit features a robust 200 mm diameter and a durable alloy steel body with tungsten carbide buttons, ensuring exceptional wear resistance and impact toughness. The K80 is compatible with high-pressure DTH hammers and is ideal for drilling hard rock formations such as granite, basalt, and limestone. Its optimized face design and flushing holes improve hole cleaning and penetration rate, reducing overall drilling costs. Whether you are drilling blast holes in open-pit mines or water wells in tough geological conditions, the Kaishan K80 delivers reliable performance and long service life. Backed by Kaishan's global service network, this bit is a cost-effective choice for contractors seeking productivity and durability.

Best For

Open-Pit Mining Quarrying Water Well Drilling Construction

Technical Specifications

Model	K80
Type	DTH Drill Bit
Size	200 mm (8 inch)
Application	Mining, quarrying, water well drilling
Material	Alloy steel body with tungsten carbide buttons
Weight	Approx. 25 kg
Packing	Wooden case or carton

Get a Quote Check Fit

Selection Advantages Applications Comparison Components Principle Features Packaging Service FAQ

Product Details

## Overview The Kaishan K80 is a premium down-the-hole (DTH) drill bit engineered for high-efficiency rock drilling in mining, quarrying, and water well applications. As part of Kaishan's extensive Drilling Tools line, this bit is specifically designed to match high-pressure DTH hammers, delivering superior penetration rates and extended service life in the most challenging formations. ## Technical Features The K80 features a 200 mm (8-inch) diameter and a flat face design with hemispherical buttons, optimized for hard and abrasive rock. The bit body is machined from high-quality alloy steel and heat-treated for maximum strength and fatigue resistance. Tungsten carbide buttons are strategically arranged to balance wear and impact loading, ensuring consistent performance. Multiple flushing holes effectively remove cuttings and cool the bit, preventing regrinding and enhancing drilling efficiency. The bit shank is compatible with standard DTH hammers, ensuring easy integration into existing drill strings. ## Applications This DTH drill bit is widely used in open-pit mining, quarrying, construction, and water well drilling. It excels in hard rock conditions such as granite, basalt, quartzite, and limestone. The K80 is particularly effective in blast hole drilling where high productivity and hole accuracy are critical. Its robust design also makes it suitable for geothermal drilling and foundation work. ## Why Choose Kaishan K80 Kaishan is a globally recognized manufacturer of drilling equipment and tools, with decades of experience in rock drilling technology. The K80 bit is manufactured under strict quality control and tested for performance and durability. By choosing the Kaishan K80, contractors benefit from reduced drilling costs, fewer bit changes, and increased overall productivity. The bit is available for immediate shipment and is supported by Kaishan's worldwide service network.

Technical Selection

Key parameters for matching this machine to your job. Send us your hole diameter, depth and rock condition and our engineers will confirm the right configuration.

Weight

Approx. 25 kg

Model

K80

Type

DTH Drill Bit

Size

200 mm (8 inch)

Application

Mining, quarrying, water well drilling

Material

Alloy steel body with tungsten carbide buttons

Packing

Wooden case or carton

Not sure this model fits? Tell us the hole diameter and depth — we will confirm the matching rig, compressor and hammer.

Check with an engineer

Key Advantages

✓

200 mm diameter for efficient large-hole drilling

✓

High-quality tungsten carbide buttons for extended wear life

✓

Heat-treated alloy steel body for superior strength

✓

Optimized face design for faster penetration

✓

Multiple flushing holes for effective hole cleaning

✓

Compatible with standard DTH hammers

✓

Suitable for hard rock formations

✓

Cost-effective and reliable performance

Applications

📍 Open-Pit Mining

Blast hole drilling in hard rock mines.

Solution: K80 DTH bit delivers high penetration rates and long life, reducing drilling costs.

📍 Quarrying

Drilling blast holes in granite, limestone, and other quarry materials.

Solution: Durable carbide buttons and optimized flushing ensure efficient drilling and hole quality.

📍 Water Well Drilling

Drilling water wells in hard rock formations.

Solution: Reliable performance and compatibility with DTH hammers for deep well drilling.

📍 Construction

Foundation drilling and site preparation.

Solution: K80 provides accurate hole alignment and fast drilling in tough conditions.

Similar Models in This Category

This model is unique in its series — here are similar models from the same category.

Model	Model	Type	Size	Application	Material	Inquire
K80This model	K80	DTH Drill Bit	200 mm (8 inch)	Mining, quarrying, water well drilling	Alloy steel body with tungsten carbide buttons	Get a Quote
K10	K10	DTH Drill Bit (Down-the-Hole Button Bit)	90–130 mm diameter (customizable)	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
K3	K3	DTH Drill Bit	76mm - 152mm	Mining, Quarrying, Water Well Drilling	Alloy Steel with Carbide Buttons	Get a Quote
K30	K30	DTH Button Bit	76mm - 152mm (customizable)	Mining, Quarrying, Water Well, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote
K4	K4	DTH Drill Bit	Φ110 mm (standard); other sizes available	Mining, water well drilling, quarrying, construction	Alloy steel body with carbide button inserts	Get a Quote
K40	K40	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
K5	K5	DTH Button Bit	130 mm - 152 mm diameter	Mining, quarrying, water well drilling, foundation engineering	Alloy steel body with tungsten carbide buttons	Get a Quote
K50	K50	DTH Drill Bit (Button Bit)	5 inch (127 mm) shank, 130-140 mm diameter	Mining, quarrying, water well drilling, construction	Alloy steel body with tungsten carbide buttons	Get a Quote
K6	K6	DTH Button Bit	76mm - 152mm (3" - 6")	Mining, Quarrying, Water Well Drilling, Construction	Alloy Steel Body with Tungsten Carbide Buttons	Get a Quote

Compare 2–3 models? Tick the boxes and send them together — we will quote each one for you.

Inquire All

Tip: select multiple models and click “Inquire All” — the selected models are added to the quote form automatically, so you get a faster quotation.

Not sure which model fits your project? Send us your working pressure and air demand — our engineers will recommend the right one.

Get a Recommendation 💬 WhatsApp

Main Components

Bit body
Tungsten carbide buttons
Flushing holes
Shank
Splines
Retaining ring
Chuck
Wear sleeve

Working Principle

The Kaishan K80 DTH drill bit operates on the principle of down-the-hole percussion. High-pressure air is supplied through the drill string to the DTH hammer, which directly drives the bit's piston. The piston strikes the bit shank, transferring impact energy to the tungsten carbide buttons. Simultaneously, the bit rotates slowly, causing the buttons to crush and fracture the rock. The air then flushes the cuttings out of the hole through the flushing holes. This combined impact and rotation action allows for efficient drilling in hard rock. The design of the bit ensures that the impact energy is effectively transmitted to the rock, while the flushing holes maintain a clean hole bottom. The K80's button layout and face design are optimized to balance wear and penetration rate, resulting in a long service life and high productivity.

Detailed Features

▸High wear resistance
▸Excellent impact toughness
▸Fast penetration rate
▸Long service life
▸Reliable performance
▸Easy to replace
▸Compatible with major DTH hammers
▸Cost-effective

Packaging & Shipping

Each Kaishan K80 DTH drill bit is packed in a sturdy wooden case or carton, depending on order quantity, to ensure safe transport. For bulk orders, bits are palletized and shrink-wrapped. We ship from Shanghai or Ningbo port, with lead times of 15-30 days after order confirmation. Air and sea freight options are available.

After-Sales Service

Kaishan offers a 6-month warranty on the K80 DTH drill bit against manufacturing defects. Our 24-hour technical support team is available to assist with product selection and troubleshooting. We provide on-site training for proper use and maintenance. Genuine spare parts are available worldwide through our distribution network.
